May, 2007 V-SYNTH/GT
JACK, EXT TERMINAL
13429274 MIDI SOCKET YKF51-5041 JK1 on MIDI Board 1
# 04459190 PLUG YKF45-0033N JK1 on Main Board 1
02781189 USB CONNECTOR B TYPE FE-
MALE
YKF45-0021 JK2 on Main Board 1
03231812 RCA (PIN) YKC21-4173 JK4 on Main Board 1
00120434 JACK YKB21-5262 JK9, JK11, JK5, JK6, JK8, JK10 on Jack Board,
JK2, JK3, JK4 on MIDI Board
9
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) JK12 on Jack Board 1
02232412 XLR CONNECTOR NCJ6FI-H-0 JK7 on Jack Board 1
# 04125012 OPTICAL CONNECTOR GP1FMV51TK0F CN11 on Main Board 1
03453389 IC (OPTICAL) GP1FM313RZOF CN12 on Main Board 1
DISPLAY UNIT
# 73456989 LCD ASSY 1
POWER SUPPLY UNIT
# 04561723 SWITCHING REGULATOR LEA50F-5-SXRLD 1
BENDER UNIT
03234723 BENDER PB-H0204 1
SPEAKER, BUZZER
03900712 SPEAKER TWEETER PKM13EPYH4002-B0 SP1 on SUB Board 1
KEYBOARD ASSY
# 73780967 KEYBOARD ASSY SK-1061-A 1
PWB ASSY
# 73459834 BENDER BOARD ASSY 1
# 73459812 EN BOARD ASSY 1
# 73459790 INLET BOARD ASSY 1
# 73459756 JACK BOARD ASSY 1
# 73456990 MAIN BOARD ASSY 1
# 73459767 MIDI BOARD ASSY 1
# 73459789 PAD BOARD ASSY 1
# 73459801 PANEL-L BOARD ASSY 1
# 73457101 PANEL-R KEYTOP ASSY 1
# 73459690 S-BOARD ASSY 1
# 73566345 SUB BOARD ASSY 1
# 73459823 VOLUME BOARD ASSY 1
IC
04235490 PHOTO DI TPS703 (F) D1 on PANEL-L Board 1
DIODE
03126134 LED (INFRARED) TLN233 (F) LED84, LED83 on PANEL-L Board 2
03893601 LED SLR343BCT3F LED5, LED16, LED1, LED6 on PANEL-L
Board, LED25, LED22, LED23, LED24,
LED26, LED27, LED30, LED29, LED28 on
PANEL-R Board
13
03230656 LED (RED) SLR-343VCT32 LED17 on PANEL-L Board 1
02894090 LED (ORNG) SLR-343DUT32 LED32, LED31 on PANEL-R Board 2
02125167 LED (YELOW) SLI-343DCT32W LED3, LED2 on Bender Board, LED2,
LED20, LED19, LED22, LED23, LED24,
LED25, LED26, LED27, LED28, LED21,
LED4, LED15, LED14, LED3, LED12,
LED41, LED29, LED7, LED8, LED11,
LED10, LED9, LED18, LED40, LED31,
LED32, LED33, LED34, LED35, LED36,
LED37, LED38, LED30, LED39 on PANEL-L
Board, LED12, LED20, LED19, LED18,
LED17, LED16, LED15, LED21, LED13,
LED3, LED11, LED10, LED9, LED8, LED7,
LED6, LED5, LED4, LED2, LED14, LED1 on
PANEL-R Board
58
