24
May, 2007 V-SYNTH/GT
POTENTIOMETER
# 04569256 POTENTIOMETER RK12L12C0C1G VR2 on PANEL-L Board 1
02891812 12M/M ROTARY POTENTI-
OMETER
RK12L12C0C08 VR1 on PANEL-L Board 1
03122123 30M/M SLIDE POTENTIOME-
TER
EWA NKE C15 B14 VR16, VR15, VR13, VR14 on PANEL-R
Board
4
# 03679378 POTENTIOMETER EVUF3KFK1B14 VR6, VR1, VR9, VR4, VR10, VR11, VR12,
VR7, VR8, VR3, VR2 on PANEL-R Board
11
01340234 POTENTIOMETER (9M/M) EVUF2K1B14 L=12.5 10KB VR3, VR4 on PANEL-L Board, VR11, VR12,
VR13, VR14, VR15, VR16, VR18, VR17 on
VOL Board
10
ENCODER
01905467 ROTARY ENCODER EVE GC1 F20 24B EN2 on EN Board, EN1 on PANEL-L Board 2
WIRING, CABLE
# 04673390 WIRING W6 1
# 04566634 WIRING W4 1
# 04566623 WIRING W3 1
# 04566601 WIRING W2 1
# 04566590 WIRING W1 1
# 04569578 WIRING SFWR-P=0.50-K-33-220 1
# 04569734 WIRING FWR-P=1.25-K-18-180 1
# 04569712 WIRING FWR-P=1.25-K-16-180 1
# 04569689 WIRING FWR-P=1.00-K-8-80 1
# 04569690 WIRING FWR-P=1.00-K-40-160 1
# 04569701 WIRING FWR-P=1.00-K-38-90 1
# 04569612 WIRING FWR-P=1.00-K-20-550 1
# 04569623 WIRING FWR-P=1.00-K-18-180 1
# 04569678 WIRING FWR-P=1.00-K-16-400 1
# 04569601 WIRING FWR-P=1.00-K-16-180 1
# 04569634 WIRING FWR-P=1.00-K-14-50 1
# 04569656 WIRING FWR-P=1.00-K-12-200 1
# 04569667 WIRING FWR-P=1.00-K-10-240 1
02341967 WIRING 4X50-P2.0-PHR-PHR-F 1
02341978 WIRING 4X100-P2.0-PHR-PHR-F 1
AC INLET, OUTLET
00125023 AC INLET PWI1818 (INL-7) 10A/250V 3P JK13 on Inlet Board 1
PICK UP, SENSOR
# 73459734 XY-PAD ASSY 1
SCREWS
40011745 HEX NUT M4 SPRING NUT FE ZC 1
40237101 SCREW M3X8 PAN MACHINE W/
SW+SMALL PW BZC
9
40013001 SCREW M4X8 PAN MACHINE W/SW+PW
BZC
5
40454045 SCREW 3X8 FLAT TAPTITEB NI FLANGE
SOCKE
8
40012501 SCREW M4X12 BINDING TAPTITE P FE BZC 1
40011312 SCREW 3X8 BINDING TAPTITE P BZC 32
40011101 SCREW 3X8 BINDING TAPTITE B BZC 63
40011123 SCREW 4X8 BINDING TAPTITE B BZC 21
40010345 SCREW M4X10 BINDING MACHINE FE BZC 1
PACKING
# 04566567 CENTER PAD UPPER 1
# 04566545 PACKING PAD R 1
# 04566556 CENTER PAD LOWER 1
# 04566534 PACKING PAD L 1
# 04566523 PACKING CASE 1
