Roland VR-120HD User Manual

3
MIDI Implementation
2. Parameter Address Map
Start Address Description Start Address Description
00H 00H 00H Video Parameter Area
18H 00H 00H Video Parameter (Scene Memory 5)
01H 00H 00H Audio Parameter Area
19H 00H 00H Audio Parameter (Scene Memory 5)
02H 00H 00H System Parameter Area 1AH 00H 00H Video Parameter (Scene Memory 6)
0AH 00H 00H Other Parameter Area 1BH 00H 00H Audio Parameter (Scene Memory 6)
0CH 00H 00H Tally Parameter Area 1CH 00H 00H Video Parameter (Scene Memory 7)
10H 00H 00H Video Parameter (Scene Memory 1) 1DH 00H 00H Audio Parameter (Scene Memory 7)
11H 00H 00H Audio Parameter (Scene Memory 1) 1EH 00H 00H Video Parameter (Scene Memory 8)
12H 00H 00H Video Parameter (Scene Memory 2) 1FH 00H 00H Audio Parameter (Scene Memory 8)
13H 00H 00H Audio Parameter (Scene Memory 2) : :
14H 00H 00H Video Parameter (Scene Memory 3) 4EH 00H 00H Video Parameter (Scene Memory 32)
15H 00H 00H Audio Parameter (Scene Memory 3) 4FH 00H 00H Audio Parameter (Scene Memory 32)
16H 00H 00H Video Parameter (Scene Memory 4) 60H 00H 00H Memory Name
17H 00H 00H Audio Parameter (Scene Memory 4)
ÁVideo Parameter Area
À VIDEO ASSIGN
Address Parameter Name Sys.Ex.Value Meaning of Value
00H 00H 00H
Input 1 Assign 00H–20H
HDMI In 1–6, SDI In 1–6, Still 1–16, Video Player, Stream/Record Status 1, Stream/
Record Status 2, Date&time
00H 00H 01H Input 2 Assign 00H–20H
HDMI In 1–6, SDI In 1–6, Still 1–16, Video Player, Stream/Record Status 1, Stream/
Record Status 2, Date&time
00H 00H 02H Input 3 Assign 00H–20H
HDMI In 1–6, SDI In 1–6, Still 1–16, Video Player, Stream/Record Status 1, Stream/
Record Status 2, Date&time
00H 00H 03H Input 4 Assign 00H–20H
HDMI In 1–6, SDI In 1–6, Still 1–16, Video Player, Stream/Record Status 1, Stream/
Record Status 2, Date&time
00H 00H 04H Input 5 Assign 00H–20H
HDMI In 1–6, SDI In 1–6, Still 1–16, Video Player, Stream/Record Status 1, Stream/
Record Status 2, Date&time
00H 00H 05H Input 6 Assign 00H–20H
HDMI In 1–6, SDI In 1–6, Still 1–16, Video Player, Stream/Record Status 1, Stream/
Record Status 2, Date&time
00H 00H 06H Input 7 Assign 00H–20H
HDMI In 1–6, SDI In 1–6, Still 1–16, Video Player, Stream/Record Status 1, Stream/
Record Status 2, Date&time
00H 00H 07H Input 8 Assign 00H–20H
HDMI In 1–6, SDI In 1–6, Still 1–16, Video Player, Stream/Record Status 1, Stream/
Record Status 2, Date&time
00H 00H 08H HDMI Out 1 Assign 00H–06H Program, Sub Program, Preview, Aux, Multi-View, Input-View, Still-View
00H 00H 09H HDMI Out 2 Assign 00H–06H Program, Sub Program, Preview, Aux, Multi-View, Input-View, Still-View
00H 00H 0AH HDMI Out 3 Assign 00H–06H Program, Sub Program, Preview, Aux, Multi-View, Input-View, Still-View
00H 00H 0BH SDI Out 1 Assign 00H–06H Program, Sub Program, Preview, Aux, Multi-View, Input-View, Still-View
00H 00H 0CH SDI Out 2 Assign 00H–06H Program, Sub Program, Preview, Aux, Multi-View, Input-View, Still-View
00H 00H 0DH SDI Out 3 Assign 00H–06H Program, Sub Program, Preview, Aux, Multi-View, Input-View, Still-View
00H 00H 0EH USB Out Assign 00H–06H Program, Sub Program, Preview, Aux, Multi-View, Input-View, Still-View
00H 00H 0FH Stream/Record Assign 00H–06H Program, Sub Program, Preview, Aux, Multi-View, Input-View, Still-View
00H 00H 10H LCD Monitor Assign 00H–06H Program, Sub Program, Preview, Aux, Multi-View, Input-View, Still-View
00H 00H 11H Aux Source 00H–24H HDMI In 1–6, SDI In 1–6, Still 1–16, Video Player, Input 1–8
00H 00H 12H Program Layer PinP&Key 1 00H–01H Disable, Enable
00H 00H 13H Program Layer PinP&Key 2 00H–01H Disable, Enable
00H 00H 14H Program Layer PinP&Key 3 00H–01H Disable, Enable
00H 00H 15H Program Layer PinP&Key 4 00H–01H Disable, Enable
00H 00H 16H Program Layer DSK 1 00H–01H Disable, Enable
00H 00H 17H Program Layer DSK 2 00H–01H Disable, Enable
00H 00H 18H Sub Program Layer PinP&Key 1 00H–01H Disable, Enable
00H 00H 19H Sub Program Layer PinP&Key 2 00H–01H Disable, Enable
00H 00H 1AH Sub Program Layer PinP&Key 3 00H–01H Disable, Enable
00H 00H 1BH Sub Program Layer PinP&Key 4 00H–01H Disable, Enable
00H 00H 1CH Sub Program Layer DSK 1 00H–01H Disable, Enable
00H 00H 1DH Sub Program Layer DSK 2 00H–01H Disable, Enable
00H 00H 1EH Aux Layer PinP&Key 1 00H–02H O, PGM Sync, On
00H 00H 1FH Aux Layer PinP&Key 2 00H–02H O, PGM Sync, On
00H 00H 20H Aux Layer PinP&Key 3 00H–02H O, PGM Sync, On
00H 00H 21H Aux Layer PinP&Key 4 00H–02H O, PGM Sync, On
