Roland VR-120HD User Manual

43
LAN/RS-232 Command Reference
List of Commands
See “MIDI Implementation” (p. 2) for the SysEx addresses and setting values.
* When controlling via LAN (Telnet), “stx (02H)” may be omitted.
Item
Sent
command
Response
command
Parameter
Parameter write
(SysEx-supported command)
stxDTH:a,b; ack a:
b:
SysEx address (hexadecimal, three bytes)
Setting value (hexadecimal)
<Example> When setting “01H” to address 12H 34H 56H Ó stx-
DTH:123456,01;
Parameter value retrieve
(SysEx-supported command)
stxRQH:a,b; stxDTH:a,c; a:
b:
c:
SysEx address (hexadecimal, three bytes)
Request size (hexadecimal, three bytes)
Setting value (hexadecimal)
Version information stxVER; stxVER:a,b; a: VR-120HD (Product name)
b: Version number <Example> 1.00
Flow control xon
Flow control xo
Commands spontaneously sent from theVR-120HD
Item
Sent
command
Response
command
Parameter
Error detected
stxERR:a; a: 0 (syntax error) The received command contains an error.
4 (invalid) This has no eect because it is controlled by another setting.
5 (out of range error) An argument of the received command is out of
range.
6 (no stx error) The command does not have a “stx” prex. * Only RS-232
Flow control
xon
Flow control
xo
