Roland VR-6HD

10
MIDI Implementation
À AUDIO AUX 1 SEND
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 23H 00H
01H
02H
AUDIO IN 1 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 03H
04H
05H
AUDIO IN 2 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 06H
07H
08H
AUDIO IN 3 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 09H
0AH
0BH
AUDIO IN 4 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 0CH
0DH
0EH
AUDIO IN 5 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 0FH
10H
11H
AUDIO IN 6 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 12H
13H
14H
AUDIO IN 7/8 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 15H
16H
17H
USB IN SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 18H
19H
1AH
Bluetooth IN SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 1BH
1CH
1DH
AUDIO PLAYER SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 1EH
1FH
20H
VIDEO IN 1 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 21H
22H
23H
VIDEO IN 2 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 24H
25H
26H
VIDEO IN 3 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 27H
28H
29H
VIDEO IN 4 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 2AH
2BH
2CH
VIDEO IN 5 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 2DH
2EH
2FH
VIDEO IN 6 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 30H
31H
32H
VIDEO PLAYER SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 23H 33H AUDIO IN 1 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 34H AUDIO IN 2 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 35H AUDIO IN 3 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 36H AUDIO IN 4 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 37H AUDIO IN 5 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 38H AUDIO IN 6 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 39H AUDIO IN 7/8 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 3AH USB IN SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 3BH Bluetooth IN SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 3CH AUDIO PLAYER SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 3DH VIDEO IN 1 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 3EH VIDEO IN 2 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 3FH VIDEO IN 3 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 40H VIDEO IN 4 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
