MIDI Implementation
2. Parameter Address Map
Start Address Description Start Address Description
00H 00H 00H Video Parameter Area
18H 00H 00H Video Parameter (MEMORY 5) Area
01H 00H 00H Audio Parameter Area
19H 00H 00H Audio Parameter (MEMORY 5) Area
02H 00H 00H System Parameter Area 1AH 00H 00H Video Parameter (MEMORY 6) Area
0AH 00H 00H Command Area 1BH 00H 00H Audio Parameter (MEMORY 6) Area
0CH 00H 00H Tally Area 1CH 00H 00H Video Parameter (MEMORY 7) Area
10H 00H 00H Video Parameter (MEMORY 1) Area 1DH 00H 00H Audio Parameter (MEMORY 7) Area
11H 00H 00H Audio Parameter (MEMORY 1) Area 1EH 00H 00H Video Parameter (MEMORY 8) Area
12H 00H 00H Video Parameter (MEMORY 2) Area 1FH 00H 00H Audio Parameter (MEMORY 8) Area
13H 00H 00H Audio Parameter (MEMORY 2) Area : :
14H 00H 00H Video Parameter (MEMORY 3) Area 4EH 00H 00H Video Parameter (MEMORY 32) Area
15H 00H 00H Audio Parameter (MEMORY 3) Area 4FH 00H 00H Audio Parameter (MEMORY 32) Area
16H 00H 00H Video Parameter (MEMORY 4) Area 60H xxH 00H Memory Name Area
17H 00H 00H Audio Parameter (MEMORY 4) Area
ÁVideo Parameter Area
À VIDEO ASSIGN
Address Parameter Name Sys.Ex.Value Meaning of Value
00H 00H 00H
INPUT 1 ASSIGN
00H–17H VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, N/A
00H 00H 01H
INPUT 2 ASSIGN
00H–17H VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, N/A
00H 00H 02H
INPUT 3 ASSIGN 00H–17H VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, N/A
00H 00H 03H
INPUT 4 ASSIGN 00H–17H VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, N/A
00H 00H 04H
INPUT 5 ASSIGN 00H–17H VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, N/A
00H 00H 05H
INPUT 6 ASSIGN 00H–17H VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, N/A
00H 00H 06H
VIDEO OUT 1 ASSIGN 00H–05H PROGRAM, SUB PROGRAM, PREVIEW, AUX, MULTI-VIEW, STILL-VIEW
00H 00H 07H
VIDEO OUT 2 ASSIGN 00H–05H PROGRAM, SUB PROGRAM, PREVIEW, AUX, MULTI-VIEW, STILL-VIEW
00H 00H 08H
VIDEO OUT 3 ASSIGN 00H–05H PROGRAM, SUB PROGRAM, PREVIEW, AUX, MULTI-VIEW, STILL-VIEW
00H 00H 09H
USB OUT ASSIGN 00H–05H PROGRAM, SUB PROGRAM, PREVIEW, AUX, MULTI-VIEW, STILL-VIEW
00H 00H 0AH
STREAM/RECORD ASSIGN 00H–05H PROGRAM, SUB PROGRAM, PREVIEW, AUX, MULTI-VIEW, STILL-VIEW
00H 00H 0BH
LCD MONITOR ASSIGN 00H–05H PROGRAM, SUB PROGRAM, PREVIEW, AUX, MULTI-VIEW, STILL-VIEW
00H 00H 0CH
AUX SOURCE 00H–1CH VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
00H 00H 0DH
PROGRAM LAYER PINP&KEY 1 00H–01H DISABLE, ENABLE
00H 00H 0EH
PROGRAM LAYER PINP&KEY 2 00H–01H DISABLE, ENABLE
00H 00H 0FH
PROGRAM LAYER DSK 00H–01H DISABLE, ENABLE
00H 00H 10H
SUB PROGRAM LAYER PINP&KEY 1 00H–01H DISABLE, ENABLE
00H 00H 11H
SUB PROGRAM LAYER PINP&KEY 2 00H–01H DISABLE, ENABLE
00H 00H 12H
SUB PROGRAM LAYER DSK 00H–01H DISABLE, ENABLE
00H 00H 13H
AUX LAYER PINP&KEY 1 00H–02H OFF, PGM SYNC, ON
00H 00H 14H
AUX LAYER PINP&KEY 2 00H–02H OFF, PGM SYNC, ON
00H 00H 15H
AUX LAYER DSK 00H–02H OFF, PGM SYNC, ON
À VIDEO INPUT
* xxH: 01H–06H (VIDEO IN 1–6)
Address Parameter Name Sys.Ex.Value Meaning of Value
00H xxH 00H
FLICKER FILTER 00H–01H OFF, ON
00H xxH 01H
FLIP H 00H–01H OFF, ON
00H xxH 02H
FLIP V 00H–01H OFF, ON
00H xxH 03H
EDID 00H–0BH
INTERNAL, SVGA (800 x 600), XGA (1024 x 768), WXGA (1280 x 800),
FWXGA (1366 x 768), SXGA (1280 x 1024), SXGA+ (1400 x 1050),
UXGA (1600 x 1200), WUXGA (1920 x 1200), 720p, 1080i, 1080p
00H xxH 04H
05H
ZOOM 00H 64H–4EH 10H 10.0–1000.0%
00H xxH 06H
SCALING TYPE 00H–04H FULL, LETTER BOX, CROP, DOT BY DOT, MANUAL
00H xxH 07H
08H
MANUAL SIZE H 70H 30H–00H 00H–0FH 50H -2000–0–2000
00H xxH 09H
0AH
MANUAL SIZE V 70H 30H–00H 00H–0FH 50H -2000–0–2000
To Next Page
