Roland VR-6HD

4
MIDI Implementation
Address Parameter Name Sys.Ex.Value Meaning of Value
00H xxH 0BH
0CH
POSITION H 71H 00H–00H 00H–0FH 00H -1920–0–1920
00H xxH 0DH
0EH
POSITION V 76H 50H–00H 00H–09H 30H -1200–0–1200
00H xxH 0FH BRIGHTNESS 60H–00H–1FH -32–0–31
00H xxH 10H CONTRAST 60H–00H–1FH -32–0–31
00H xxH 11H SATURATION 60H–00H–1FH -32–0–31
00H xxH 12H RED 40H–00H–3FH -64–0–63
00H xxH 13H GREEN 40H–00H–3FH -64–0–63
00H xxH 14H BLUE 40H–00H–3FH -64–0–63
00H xxH 15H COLOR SPACE 00H–04H AUTO, RGB (0-255), RGB (16-235), YPbPr (SD), YPbPr (HD)
À VIDEO INPUT (VIDEO PLAYER)
Address Parameter Name Sys.Ex.Value Meaning of Value
00H 07H 00H
FLIP H 00H–01H OFF, ON
00H 07H 01H FLIP V 00H–01H OFF, ON
À VIDEO OUTPUT
* xxH: 08H–0AH (VIDEO OUT 1–3)
Address Parameter Name Sys.Ex.Value Meaning of Value
00H xxH 00H
COLOR SPACE 00H–03H YPbPr (4: 4: 4), YPbPr (4: 2: 2), RGB (0-255), RGB (16-235)
00H xxH 01H DVI-D/HDMI SIGNAL 00H–01H HDMI, DVI-D
00H xxH 02H BRIGHTNESS 40H–00H–3FH -64–0–63
00H xxH 03H CONTRAST 40H–00H–3FH -64–0–63
00H xxH 04H SATURATION 40H–00H–3FH -64–0–63
00H xxH 05H RED 40H–00H–3FH -64–0–63
00H xxH 06H GREEN 40H–00H–3FH -64–0–63
00H xxH 07H BLUE 40H–00H–3FH -64–0–63
00H xxH 08H EXTERNAL REC CONTROL 00H–01H OFF, ON
À TRANSITION, MIX, WIPE, SPLIT
Address Parameter Name Sys.Ex.Value Meaning of Value
00H 0BH 00H
TRANSITION 00H–02H MIX, WIPE, SPLIT
00H 0BH 01H MIX TYPE 00H–02H MIX, FAM, NAM
00H 0BH 02H MIX TIME 00H–28H 0.0–4.0sec
00H 0BH 03H WIPE TYPE 00H–07H
HORIZONTAL, VERTICAL, UPPER LEFT, UPPER RIGHT, LOWER LEFT, LOWER RIGHT,
H-CENTER, V-CENTER
00H 0BH 04H MIX TIME 00H–28H 0.0–4.0sec
00H 0BH 05H WIPE DIRECTION 00H–02H NORMAL, REVERSE, ROUND TRIP
00H 0BH 06H WIPE BORDER COLOR 00H–08H WHITE, YELLOW, CYAN, GREEN, MAGENTA, RED, BLUE, BLACK, SOFT EDGE
00H 0BH 07H WIPE BORDER WIDTH 00H–0EH 0–14
00H 0BH 08H SPLIT SW 00H–01H OFF, ON
00H 0BH 09H SPLIT TYPE 00H–01H SPLIT V, SPLIT H
00H 0BH 0AH
0BH
SPLIT PGM/A-CENTER 7CH 0CH–00H 00H–03H 74H -50.0–0.0–50.0%
00H 0BH 0CH
0DH
SPLIT PST/B-CENTER 7CH 0CH–00H 00H–03H 74H -50.0–0.0–50.0%
00H 0BH 0EH
0FH
SPLIT CENTER POSITION 7CH 0CH–00H 00H–03H 74H -50.0–0.0–50.0%
00H 0BH 10H SPLIT BORDER COLOR 00H–07H WHITE, YELLOW, CYAN, GREEN, MAGENTA, RED, BLUE, BLACK
00H 0BH 11H SPLIT BORDER WIDTH 00H–0EH 0–14
