Roland VR-6HD

5
MIDI Implementation
À PinP&KEY
* xxH: 0CH–0DH (PinP&KEY 1–2)
Address Parameter Name Sys.Ex.Value Meaning of Value
00H xxH 00H
TIME 00H–28H 0.0–4.0sec
00H xxH 01H PGM SW 00H–01H OFF, ON
00H xxH 02H PVW SW 00H–01H OFF, ON
00H xxH 03H SOURCE 00H–1CH VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
00H xxH 04H TYPE 00H–03H PINP, LUMINANCE-WHITE KEY, LUMINANCE-BLACK KEY, CHROMA KEY
00H xxH 05H
06H
POSITION H 78H 18H–00H 00H–07H 68H -100.0–0.0–100.0%
00H xxH 07H
08H
POSITION V 78H 18H–00H 00H–07H 68H -100.0–0.0–100.0%
00H xxH 09H
0AH
SIZE 00H 00H–07H 68H 0.0–100.0%
00H xxH 0BH
0CH
CROPPING H 00H 00H–07H 68H 0.0–100.0%
00H xxH 0DH
0EH
CROPPING V 00H 00H–07H 68H 0.0–100.0%
00H xxH 0FH SHAPE 00H–02H RECTANGLE, CIRCLE, DIAMOND
00H xxH 10H BORDER COLOR 00H–08H WHITE, YELLOW, CYAN, GREEN, MAGENTA, RED, BLUE, BLACK, SOFT EDGE
00H xxH 11H BORDER WIDTH 00H–0EH 0–14
00H xxH 12H
13H
VIEW POSITION H 7CH 0CH–00H 00H–03H 74H -50.0–0.0–50.0%
00H xxH 14H
15H
VIEW POSITION V 7CH 0CH–00H 00H–03H 74H -50.0–0.0–50.0%
00H xxH 16H
17H
VIEW ZOOM 00H 64H–03H 10H 100–400%
00H xxH 18H
19H
KEY LEVEL 00H 00H–01H 7FH 0–255
00H xxH 1AH
1BH
KEY GAIN 00H 00H–01H 7FH 0–255
00H xxH 1CH
1DH
MIX LEVEL 00H 00H–01H 7FH 0–255
00H xxH 1EH CHROMA COLOR 00H–01H GREEN, BLUE
00H xxH 1FH HUE WIDTH 62H–00H–1EH -30–0–30
00H xxH 20H
21H
HUE FINE 00H 00H–02H 68H 0–360
00H xxH 22H
23H
SATURATION WIDTH 7FH 00H–00H 00H–00H 7FH -128–0–127
00H xxH 24H
25H
SATURATION FINE 00H 00H–01H 7FH 0–255
À DSK
Address Parameter Name Sys.Ex.Value Meaning of Value
00H 0EH 00H
TIME 00H–28H 0.0–4.0sec
00H 0EH 01H PGM SW 00H–01H OFF, ON
00H 0EH 02H PVW SW 00H–01H OFF, ON
00H 0EH 03H MODE 00H–02H SELF KEY, ALPHA KEY, EXTERNAL KEY
00H 0EH 04H KEY SOURCE 00H–1CH VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
00H 0EH 05H FILL SOURCE 00H–1CH VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
00H 0EH 06H TYPE 00H–02H LUMINANCE-WHITE KEY, LUMINANCE-BLACK KEY, CHROMA KEY
00H 0EH 07H
08H
LEVEL 00H 00H–01H 7FH 0–255
00H 0EH 09H
0AH
GAIN 00H 00H–01H 7FH 0–255
00H 0EH 0BH
0CH
MIX LEVEL 00H 00H–01H 7FH 0–255
00H 0EH 0DH CHROMA COLOR 00H–01H GREEN, BLUE
00H 0EH 0EH HUE WIDTH 62H–00H–1EH -30–0–30
00H 0EH 0FH
10H
HUE FINE 00H 00H–02H 68H 0–360
00H 0EH 11H
12H
SATURATION WIDTH 7FH 00H–00H 00H–00H 7FH -128–0–127
