Roland VR-6HD

6
MIDI Implementation
Address Parameter Name Sys.Ex.Value Meaning of Value
00H 0EH 13H
14H
SATURATION FINE 00H 00H–01H 7FH 0–255
00H 0EH 15H FILL TYPE 00H–01H BUS, MATTE
00H 0EH 16H MATTE COLOR 00H–07H WHITE, YELLOW, CYAN, GREEN, MAGENTA, RED, BLUE, BLACK
00H 0EH 17H EDGE TYPE 00H–04H OFF, BORDER, DROP, SHADOW, OUTLINE
00H 0EH 18H EDGE COLOR 00H–07H WHITE, YELLOW, CYAN, GREEN, MAGENTA, RED, BLUE, BLACK
00H 0EH 19H EDGE WIDTH 00H–07H 0–7
À PANEL
Address Parameter Name Sys.Ex.Value Meaning of Value
00H 0FH 00H
PGM SELECT 00H–1CH VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
00H 0FH 01H PST SELECT 00H–1CH VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
00H 0FH 02H
03H
FADER LEVEL 00H 00H–0FH 7FH 0–2047
00H 0FH 04H DISSOLVE TAKE TYPE 00H–01H CUT, AUTO
00H 0FH 05H FADER BASE 00H–01H UPPER, LOWER
ÁAudio Parameter Area
À AUDIO FADER ASSIGN
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 00H 00H
INPUT FADER 1 00H–10H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER
01H 00H 01H INPUT FADER 2 00H–10H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER
01H 00H 02H INPUT FADER 3 00H–10H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER
01H 00H 03H INPUT FADER 4 00H–10H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER
01H 00H 04H INPUT FADER 5 00H–10H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER
01H 00H 05H INPUT FADER 6 00H–10H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER
01H 00H 06H INPUT FADER 7 00H–10H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER
À AUDIO INPUT
* xxH: 01H–11H (AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6, VIDEO PLAYER)
Address Parameter Name Sys.Ex.Value Meaning of Value
01H xxH 00H
ANALOG GAIN 00H–44H 0–68 dB
01H xxH 01H
02H
DIGITAL GAIN 7CH 5CH–00H 00H–03H 24H -42.0–0.0–42.0dB
01H xxH 03H
04H
05H
INPUT LEVEL
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H xxH 06H INPUT MUTE 00H–01H OFF, ON
01H xxH 07H PHANTOM +48V 00H–01H OFF, ON
01H xxH 08H PAN 00H–32H–64H LEFT–CENTER–RIGHT
01H xxH 09H STEREO LINK 00H–01H OFF, ON
01H xxH 0AH MONO 00H–03H OFF, L ONLY, R ONLY, LR MIX
01H xxH 0BH SOLO 00H–01H OFF, ON
01H xxH 0CH MAIN SEND 00H–01H OFF, ON
01H xxH 0DH EFFECT PRESET 00H–04H DEFAULT, MEETING, INTERVIEW, AMBIENT MIC, WINDY FIELD
01H xxH 0EH
0FH
DELAY 00H 00H–27H 08H 0.0–500.0msec
01H xxH 10H REVERB SEND 00H–7FH 0–127
01H xxH 11H HIGH PASS FILTER 80HZ 00H–01H OFF, ON
01H xxH 12H ECHO CANELLER SW 00H–01H OFF, ON
01H xxH 13H ECHO CANELLER DEPTH 01H–0AH 1–10
01H xxH 14H HOWLING CANCELLER 00H–01H OFF, ON
