Roland VR-6HD

7
MIDI Implementation
Address Parameter Name Sys.Ex.Value Meaning of Value
01H xxH 15H
DE-ESSER SW 00H–01H OFF, ON
01H xxH 16H DE-ESSER SENS 00H–64H 0–100
01H xxH 17H DE-ESSER DEPTH 00H–64H 0–100
01H xxH 18H NOISE GATE SW 00H–01H OFF, ON
01H xxH 19H NOISE GATE THRESHOLD 30H–00H -80–0dB
01H xxH 1AH NOISE GATE RELEASE 00H–7FH 30–5000msec
01H xxH 1BH COMPRESSOR SW 00H–01H OFF, ON
01H xxH 1CH COMPRESSOR THRESHOLD 4EH–00H -50–0dB
01H xxH 1DH COMPRESSOR RATIO 00H–0DH
1.00: 1, 1.12: 1, 1.25: 1, 1.40: 1, 1.60: 1, 1.80: 1, 2.00: 1, 2.50: 1, 3.20: 1, 4.00: 1,
5.60: 1, 8.00: 1, 16.0: 1, INF: 1
01H xxH 1EH COMPRESSOR ATTACK 00H–73H 0.0–100msec
01H xxH 1FH COMPRESSOR RELEASE 00H–7FH 30–5000msec
01H xxH 20H COMPRESSOR MAKEUP GAIN 58H–00H–28H -40–0–40dB
01H xxH 21H EQUALIZER SW 00H–01H OFF, ON
01H xxH 22H EQUALIZER Hi GAIN 04H–7CH -12.0–12.0dB
01H xxH 23H EQUALIZER Hi FREQUENCY 24H–3EH 1.00–20.0kHz
01H xxH 24H EQUALIZER Lo-Mid GAIN 04H–7CH -12.0–12.0dB
01H xxH 25H EQUALIZER Lo-Mid FREQUENCY 02H–3EH 20Hz–20.0kHz
01H xxH 26H EQUALIZER Lo-Mid Q 00H–05H 0.5, 1.0, 2.0, 4.0, 8.0, 16.0
01H xxH 27H EQUALIZER Hi-Mid GAIN 04H–7CH -12.0–12.0dB
01H xxH 28H EQUALIZER Hi-Mid FREQUENCY 02H–3EH 20Hz–20.0kHz
01H xxH 29H EQUALIZER Hi-Mid Q 00H–05H 0.5, 1.0, 2.0, 4.0, 8.0, 16.0
01H xxH 2AH EQUALIZER Lo GAIN 04H–7CH -12.0–12.0dB
01H xxH 2BH EQUALIZER Lo FREQUENCY 02H–2AH 20Hz–2.00kHz
01H xxH 2CH VOICE CHANGER SW 00H–01H OFF, ON
01H xxH 2DH VOICE CHANGER PITCH 74H–00H–0CH -12–0–+12
01H xxH 2EH VOICE CHANGER FORMANT 76H–00H–0AH -10–0–+10
01H xxH 2FH VOICE CHANGER ROBOT 00H–01H OFF, ON
01H xxH 30H VOICE CHANGER MIX 00H–64H 0–100
01H xxH 31H EMBEDDED AUDIO CHANNEL 00H–03H 1/2, 3/4, 5/6, 7/8
À AUDIO OUTPUT ASSIGN
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 20H 00H
AUDIO OUT 1 (XLR) 00H–03H MAIN BUS, AUX 1 BUS, AUX 2 BUS, MONITOR
01H 22H 01H AUDIO OUT 2 (RCA) 00H–03H MAIN BUS, AUX 1 BUS, AUX 2 BUS, MONITOR
01H 20H 02H PHONES OUT / MONITOR 00H–02H MAIN BUS, AUX 1 BUS, AUX 2 BUS
01H 20H 03H USB OUT 00H–02H MAIN BUS, AUX 1 BUS, AUX 2 BUS
01H 20H 04H STREAM/RECORD 00H–02H MAIN BUS, AUX 1 BUS, AUX 2 BUS
01H 20H 05H AUDIO RECORD 00H–02H MAIN BUS, AUX 1 BUS, AUX 2 BUS
01H 20H 06H VIDEO OUT 1 00H–03H MAIN BUS, AUX 1 BUS, AUX 2 BUS, MONITOR
01H 20H 07H VIDEO OUT 2 00H–03H MAIN BUS, AUX 1 BUS, AUX 2 BUS, MONITOR
01H 20H 08H VIDEO OUT 3 00H–03H MAIN BUS, AUX 1 BUS, AUX 2 BUS, MONITOR
À AUDIO MAIN BUS
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 21H 00H
01H
02H
LEVEL
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 21H 03H MUTE 00H–01H OFF, ON
01H 21H 04H SOLO 00H–01H OFF, ON
01H 21H 05H
06H
DELAY 00H 00H–27H 08H 0.0–500.0msec
01H 21H 07H COMPRESSOR/LIMITER TYPE 00H–01H COMPRESSOR, LIMITER
01H 21H 08H COMPRESSOR/LIMITER SW 00H–01H OFF, ON
01H 21H 09H LIMITER THRESHOLD 58H–00H -40–0dB
01H 21H 0AH COMPRESSOR THRESHOLD 4EH–00H -50–0dB
01H 21H 0BH COMPRESSOR RATIO 00H–0DH
1.00: 1, 1.12: 1, 1.25: 1, 1.40: 1, 1.60: 1, 1.80: 1, 2.00: 1, 2.50: 1, 3.20: 1, 4.00: 1,
5.60: 1, 8.00: 1, 16.0: 1, INF: 1
01H 21H 0CH COMPRESSOR ATTACK 00H–73H 0.0–100msec
01H 21H 0DH COMPRESSOR RELEASE 00H–7FH 30–5000msec
01H 21H 0EH COMPRESSOR MAKEUP GAIN 58H–00H–28H -40–0–40dB
