Roland VR-6HD

11
MIDI Implementation
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 23H 41H
VIDEO IN 5 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 42H VIDEO IN 6 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 23H 43H VIDEO PLAYER SEND POINT 00H–02H DRY, PRE FADER, POST FADER
À AUDIO AUX 2 BUS
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 24H 00H
01H
02H
LEVEL
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 24H 03H MUTE 00H–01H OFF, ON
01H 24H 04H SOLO 00H–01H OFF, ON
01H 24H 05H
06H
DELAY 00H 00H–27H 08H 0.0–500.0msec
01H 24H 07H COMPRESSOR/LIMITER TYPE 00H–01H COMPRESSOR, LIMITER
01H 24H 08H COMPRESSOR/LIMITER SW 00H–01H OFF, ON
01H 24H 09H LIMITER THRESHOLD 58H–00H -40–0dB
01H 24H 0AH COMPRESSOR THRESHOLD 4EH–00H -50–0dB
01H 24H 0BH COMPRESSOR RATIO 00H–0DH
1.00: 1, 1.12: 1, 1.25: 1, 1.40: 1, 1.60: 1, 1.80: 1, 2.00: 1, 2.50: 1, 3.20: 1, 4.00: 1,
5.60: 1, 8.00: 1, 16.0: 1, INF: 1
01H 24H 0CH COMPRESSOR ATTACK 00H–73H 0.0–100msec
01H 24H 0DH COMPRESSOR RELEASE 00H–7FH 30–5000msec
01H 24H 0EH COMPRESSOR MAKEUP GAIN 58H–00H–28H -40–0–40dB
01H 24H 0FH
10H
11H
REVERB RETURN LEVEL
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 24H 12H EQUALIZER SW 00H–01H OFF, ON
01H 24H 13H EQUALIZER Hi GAIN 04H–7CH -12.0–12.0dB
01H 24H 14H EQUALIZER Hi FREQUENCY 24H–3EH 1.00–20.0kHz
01H 24H 15H EQUALIZER Lo-Mid GAIN 04H–7CH -12.0–12.0dB
01H 24H 16H EQUALIZER Lo-Mid FREQUENCY 02H–3EH 20Hz–20.0kHz
01H 24H 17H EQUALIZER Lo-Mid Q 00H–05H 0.5, 1.0, 2.0, 4.0, 8.0, 16.0
01H 24H 18H EQUALIZER Hi-Mid GAIN 04H–7CH -12.0–12.0dB
01H 24H 19H EQUALIZER Hi-Mid FREQUENCY 02H–3EH 20Hz–20.0kHz
01H 24H 1AH EQUALIZER Hi-Mid Q 00H–05H 0.5, 1.0, 2.0, 4.0, 8.0, 16.0
01H 24H 1BH EQUALIZER Lo GAIN 04H–7CH -12.0–12.0dB
01H 24H 1CH EQUALIZER Lo FREQUENCY 02H–2AH 20Hz–2.00kHz
01H 24H 1DH GEQ SW 00H–01H OFF, ON
01H 24H 1EH
1FH
GEQ GAIN 25Hz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 20H
21H
GEQ GAIN 40Hz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 22H
23H
GEQ GAIN 60Hz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 24H
25H
GEQ GAIN 100Hz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 26H
27H
GEQ GAIN 160Hz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 28H
29H
GEQ GAIN 250Hz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 2AH
2BH
GEQ GAIN 400Hz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 2CH
2DH
GEQ GAIN 630Hz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 2EH
2FH
GEQ GAIN 1kHz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 30H
31H
GEQ GAIN 1.6kHz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 32H
33H
GEQ GAIN 2.5kHz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 34H
35H
GEQ GAIN 4kHz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 36H
37H
GEQ GAIN 6.3Hz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
