Roland VR-6HD

12
MIDI Implementation
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 24H 38H
39H
GEQ GAIN 10kHz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
01H 24H 3AH
3BH
GEQ GAIN 16kHz 7EH 6AH–00H 00H–01H 16H -15.0–+15.0dB
À AUDIO AUX 2 SEND
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 25H 00H
01H
02H
AUDIO IN 1 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 03H
04H
05H
AUDIO IN 2 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 06H
07H
08H
AUDIO IN 3 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 09H
0AH
0BH
AUDIO IN 4 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 0CH
0DH
0EH
AUDIO IN 5 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 0FH
10H
11H
AUDIO IN 6 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 12H
13H
14H
AUDIO IN 7/8 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 15H
16H
17H
USB IN SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 18H
19H
1AH
Bluetooth IN SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 1BH
1CH
1DH
AUDIO PLAYER SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 1EH
1FH
20H
VIDEO IN 1 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 21H
22H
23H
VIDEO IN 2 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 24H
25H
26H
VIDEO IN 3 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 27H
28H
29H
VIDEO IN 4 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 2AH
2BH
2CH
VIDEO IN 5 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 2DH
2EH
2FH
VIDEO IN 6 SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 30H
31H
32H
VIDEO PLAYER SEND
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 25H 33H AUDIO IN 1 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 34H AUDIO IN 2 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 35H AUDIO IN 3 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 36H AUDIO IN 4 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 37H AUDIO IN 5 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 38H AUDIO IN 6 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 39H AUDIO IN 7/8 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 3AH USB IN SEND POINT 00H–02H DRY, PRE FADER, POST FADER
