Roland VR-6HD

13
MIDI Implementation
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 25H 3BH
Bluetooth IN SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 3CH AUDIO PLAYER SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 3DH VIDEO IN 1 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 3EH VIDEO IN 2 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 3FH VIDEO IN 3 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 40H VIDEO IN 4 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 41H VIDEO IN 5 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 42H VIDEO IN 6 SEND POINT 00H–02H DRY, PRE FADER, POST FADER
01H 25H 43H VIDEO PLAYER SEND POINT 00H–02H DRY, PRE FADER, POST FADER
À AUDIO USB OUTPUT
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 26H 00H
01H
02H
LEVEL
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 26H 03H MUTE 00H–01H OFF, ON
01H 26H 04H
05H
DELAY 00H 00H–27H 08H 0.0–500.0msec
01H 26H 06H EQUALIZER SW 00H–01H OFF, ON
01H 26H 07H EQUALIZER Hi GAIN 04H–7CH -12.0–12.0dB
01H 26H 08H EQUALIZER Hi FREQUENCY 24H–3EH 1.00–20.0kHz
01H 26H 09H EQUALIZER Lo-Mid GAIN 04H–7CH -12.0–12.0dB
01H 26H 0AH EQUALIZER Lo-Mid FREQUENCY 02H–3EH 20Hz–20.0kHz
01H 26H 0BH EQUALIZER Lo-Mid Q 00H–05H 0.5, 1.0, 2.0, 4.0, 8.0, 16.0
01H 26H 0CH EQUALIZER Hi-Mid GAIN 04H–7CH -12.0–12.0dB
01H 26H 0DH EQUALIZER Hi-Mid FREQUENCY 02H–3EH 20Hz–20.0kHz
01H 26H 0EH EQUALIZER Hi-Mid Q 00H–05H 0.5, 1.0, 2.0, 4.0, 8.0, 16.0
01H 26H 0FH EQUALIZER Lo GAIN 04H–7CH -12.0–12.0dB
01H 26H 10H EQUALIZER Lo FREQUENCY 02H–2AH 20Hz–2.00kHz
À AUDIO STREAM/RECORD
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 27H 00H
01H
02H
LEVEL
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
01H 27H 03H MUTE 00H–01H OFF, ON
01H 27H 04H
05H
DELAY 00H 00H–27H 08H 0.0–500.0msec
01H 27H 06H EQUALIZER SW 00H–01H OFF, ON
01H 27H 07H EQUALIZER Hi GAIN 04H–7CH -12.0–12.0dB
01H 27H 08H EQUALIZER Hi FREQUENCY 24H–3EH 1.00–20.0kHz
01H 27H 09H EQUALIZER Lo-Mid GAIN 04H–7CH -12.0–12.0dB
01H 27H 0AH EQUALIZER Lo-Mid FREQUENCY 02H–3EH 20Hz–20.0kHz
01H 27H 0BH EQUALIZER Lo-Mid Q 00H–05H 0.5, 1.0, 2.0, 4.0, 8.0, 16.0
01H 27H 0CH EQUALIZER Hi-Mid GAIN 04H–7CH -12.0–12.0dB
01H 27H 0DH EQUALIZER Hi-Mid FREQUENCY 02H–3EH 20Hz–20.0kHz
01H 27H 0EH EQUALIZER Hi-Mid Q 00H–05H 0.5, 1.0, 2.0, 4.0, 8.0, 16.0
01H 27H 0FH EQUALIZER Lo GAIN 04H–7CH -12.0–12.0dB
01H 27H 10H EQUALIZER Lo FREQUENCY 02H–2AH 20Hz–2.00kHz
À MONITOR
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 28H 00H
01H
02H
LEVEL
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–
00H 00H 64H
-INFdB, -80.0–0.0–10.0dB
