Roland VR-6HD

14
MIDI Implementation
À AUDIO EMBEDDED
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 29H 00H
VIDEO OUT 1-3 SEND (CHANNEL 3/4) 00H–0EH
N/A, AUDIO IN 1/2, AUDIO IN 3/4, AUDIO IN 5/6, AUDIO IN 7/8, USB IN,
Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6, VIDEO PLAYER
01H 29H 01H VIDEO OUT 1-3 SEND (CHANNEL 5/6) 00H–0EH
N/A, AUDIO IN 1/2, AUDIO IN 3/4, AUDIO IN 5/6, AUDIO IN 7/8, USB IN,
Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6, VIDEO PLAYER
01H 29H 02H VIDEO OUT 1-3 SEND (CHANNEL 7/8) 00H–0EH
N/A, AUDIO IN 1/2, AUDIO IN 3/4, AUDIO IN 5/6, AUDIO IN 7/8, USB IN,
Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6, VIDEO PLAYER
01H 29H 03H AUDIO IN 1 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 04H AUDIO IN 2 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 05H AUDIO IN 3 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 06H AUDIO IN 4 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 07H AUDIO IN 5 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 08H AUDIO IN 6 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 09H AUDIO IN 7/8 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 0AH USB IN EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 0BH Bluetooth IN EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 0CH AUDIO PLAYER EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 0DH VIDEO IN 1 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 0EH VIDEO IN 2 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 0FH VIDEO IN 3 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 10H VIDEO IN 4 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 11H VIDEO IN 5 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 12H VIDEO IN 6 EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
01H 29H 13H VIDEO PLAYER EMBEDDED POSITION 00H–03H OFF, DRY, PRE FADER, POST FADER
À AUDIO FOLLOW
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 30H 00H
VIDEO IN 1 00H–01H OFF, ON
01H 30H 01H VIDEO IN 2 00H–01H OFF, ON
01H 30H 02H VIDEO IN 3 00H–01H OFF, ON
01H 30H 03H VIDEO IN 4 00H–01H OFF, ON
01H 30H 04H VIDEO IN 5 00H–01H OFF, ON
01H 30H 05H VIDEO IN 6 00H–01H OFF, ON
01H 30H 06H VIDEO PLAYER 00H–01H OFF, ON
01H 30H 07H AUDIO IN 1 00H–1DH OFF, VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
01H 30H 08H AUDIO IN 2 00H–1DH OFF, VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
01H 30H 09H AUDIO IN 3 00H–1DH OFF, VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
01H 30H 0AH AUDIO IN 4 00H–1DH OFF, VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
01H 30H 0BH AUDIO IN 5 00H–1DH OFF, VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
01H 30H 0CH AUDIO IN 6 00H–1DH OFF, VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
01H 30H 0DH AUDIO IN 7/8 00H–1DH OFF, VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
01H 30H 0EH USB IN 00H–1DH OFF, VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
01H 30H 0FH Bluetooth IN 00H–1DH OFF, VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
01H 30H 10H AUDIO PLAYER 00H–1DH OFF, VIDEO IN 1–6, STILL 1–16, VIDEO PLAYER, INPUT 1–6
01H 30H 11H PinP&KEY 1 FOLLOW 00H–01H OFF, ON
01H 30H 12H PinP&KEY 2 FOLLOW 00H–01H OFF, ON
01H 30H 13H DSK FOLLOW 00H–01H OFF, ON
À AUDIO AUTO MIXING
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 31H 00H
AUTO MIXING SW 00H–01H OFF, ON
01H 31H 01H AUDIO IN 1 00H–01H DISABLE, ENABLE
01H 31H 02H AUDIO IN 2 00H–01H DISABLE, ENABLE
01H 31H 03H AUDIO IN 3 00H–01H DISABLE, ENABLE
01H 31H 04H AUDIO IN 4 00H–01H DISABLE, ENABLE
01H 31H 05H AUDIO IN 5 00H–01H DISABLE, ENABLE
01H 31H 06H AUDIO IN 6 00H–01H DISABLE, ENABLE
01H 31H 07H AUDIO IN 7/8 00H–01H DISABLE, ENABLE
01H 31H 08H USB IN 00H–01H DISABLE, ENABLE
01H 31H 09H Bluetooth IN 00H–01H DISABLE, ENABLE
