Roland VR-6HD

15
MIDI Implementation
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 31H 0AH
AUDIO PLAYER 00H–01H DISABLE, ENABLE
01H 31H 0BH VIDEO IN 1 00H–01H DISABLE, ENABLE
01H 31H 0CH VIDEO IN 2 00H–01H DISABLE, ENABLE
01H 31H 0DH VIDEO IN 3 00H–01H DISABLE, ENABLE
01H 31H 0EH VIDEO IN 4 00H–01H DISABLE, ENABLE
01H 31H 0FH VIDEO IN 5 00H–01H DISABLE, ENABLE
01H 31H 10H VIDEO IN 6 00H–01H DISABLE, ENABLE
01H 31H 11H VIDEO PLAYER 00H–01H DISABLE, ENABLE
01H 31H 12H AUDIO IN 1 WEIGHT 00H–64H 0–100%
01H 31H 13H AUDIO IN 2 WEIGHT 00H–64H 0–100%
01H 31H 14H AUDIO IN 3 WEIGHT 00H–64H 0–100%
01H 31H 15H AUDIO IN 4 WEIGHT 00H–64H 0–100%
01H 31H 16H AUDIO IN 5 WEIGHT 00H–64H 0–100%
01H 31H 17H AUDIO IN 6 WEIGHT 00H–64H 0–100%
01H 31H 18H AUDIO IN 7/8 WEIGHT 00H–64H 0–100%
01H 31H 19H USB IN WEIGHT 00H–64H 0–100%
01H 31H 1AH Bluetooth IN WEIGHT 00H–64H 0–100%
01H 31H 1BH AUDIO PLAYER WEIGHT 00H–64H 0–100%
01H 31H 1CH VIDEO IN 1 WEIGHT 00H–64H 0–100%
01H 31H 1DH VIDEO IN 2 WEIGHT 00H–64H 0–100%
01H 31H 1EH VIDEO IN 3 WEIGHT 00H–64H 0–100%
01H 31H 1FH VIDEO IN 4 WEIGHT 00H–64H 0–100%
01H 31H 20H VIDEO IN 5 WEIGHT 00H–64H 0–100%
01H 31H 21H VIDEO IN 6 WEIGHT 00H–64H 0–100%
01H 31H 22H VIDEO PLAYER WEIGHT 00H–64H 0–100%
ÁSystem Parameter Area
À Version
Address Parameter Name Sys.Ex.Value Meaning of Value
02H 00H 00H
System Version Major 00H–09H 0–9
02H 00H 01H System Version Minor (1) 00H–09H 0–9
02H 00H 02H System Version Minor (2) 00H–09H 0–9
02H 00H 03H System Version Build (1) 00H–09H 0–9
02H 00H 04H System Version Build (2) 00H–09H 0–9
02H 00H 05H System Version Build (3) 00H–09H 0–9
À SYSTEM
Address Parameter Name Sys.Ex.Value Meaning of Value
02H 01H 00H
HDCP 00H–01H OFF, ON
02H 01H 01H FRAME RATE 00H–07H 60Hz, 59.94Hz, 50Hz, 30Hz, 29.97Hz, 25Hz, 24Hz, 23.98Hz
02H 01H 02H FRAME RATE - USB OUT 00H–01H HALF RATE, NORMAL
02H 01H 03H FRAME RATE - STREAM/RECORD 00H–01H HALF RATE, NORMAL
02H 01H 04H OUTPUT FORMAT - SYSTEM FORMAT 00H–01H 1080p, 720p
02H 01H 05H OUTPUT FORMAT - VIDEO OUT 1 00H–01H 1080p, 1080i
02H 01H 06H OUTPUT FORMAT - VIDEO OUT 2 00H–01H 1080p, 1080i
02H 01H 07H OUTPUT FORMAT - VIDEO OUT 3 00H–01H 1080p, 1080i
02H 01H 08H OUTPUT FORMAT - USB OUT 00H–01H 1080p, 720p
02H 01H 09H OUTPUT FORMAT - STREAM/RECORD 00H–01H 1080p, 720p
02H 01H 0AH Bluetooth SW 00H–01H OFF, ON
02H 01H 0BH LANGUAGE 00H–02H ENGLISH, JAPANESE, SIMPLIFIED CHINESE
02H 01H 0CH PANEL OPERATION 00H–01H DISSOLVE, PGM/PST
02H 01H 0DH EFFECTS TRANSITION SYNC 00H–01H OFF, ON
02H 01H 0EH EFFECTS SPOT 00H–01H OFF, ON
02H 01H 0FH AUDIO FADER/KNOB MODE 00H–01H CATCH, DIRECT
02H 01H 10H AUX LINKED PGM 00H–02H OFF, AUTO LINK, MANUAL LINK
02H 01H 11H OUTPUT FADE ASSIGN VIDEO FADE 00H–03H N/A, BLACK, WHITE, AUX
02H 01H 12H OUTPUT FADE ASSIGN AUDIO FADE 00H–01H OFF, ON
02H 01H 13H OUTPUT FADE TIME 00H–28H 0.0–4.0sec
