Roland VR-6HD

16
MIDI Implementation
Address Parameter Name Sys.Ex.Value Meaning of Value
02H 01H 14H
15H
USER 1 ASSIGN 00H 00H–01H 5AH
See “Menu List” in the “Reference Manual” (PDF).
02H 01H 16H
17H
USER 2 ASSIGN 00H 00H–01H 5AH
02H 01H 18H
19H
USER 3 ASSIGN 00H 00H–01H 5AH
02H 01H 1AH
1BH
USER 4 ASSIGN 00H 00H–01H 5AH
02H 01H 1CH
1DH
AUDIO EFFECT 1 ASSIGN 00H 00H–01H 34H
See “Menu List” in the “Reference Manual” (PDF).
02H 01H 1EH
1FH
AUDIO EFFECT 2 ASSIGN 00H 00H–01H 34H
02H 01H 20H
21H
AUDIO EFFECT 3 ASSIGN 00H 00H–01H 34H
02H 01H 22H MONITOR 1 ASSIGN 00H–07H
N/A, MULTI-VIEW, INPUT-VIEW, STILL-VIEW, PROGRAM, SUB PROGRAM, PREVIEW,
AUX
02H 01H 23H MONITOR 2 ASSIGN 00H–07H
N/A, MULTI-VIEW, INPUT-VIEW, STILL-VIEW, PROGRAM, SUB PROGRAM, PREVIEW,
AUX
02H 01H 24H MONITOR 3 ASSIGN 00H–07H
N/A, MULTI-VIEW, INPUT-VIEW, STILL-VIEW, PROGRAM, SUB PROGRAM, PREVIEW,
AUX
02H 01H 25H MONITOR 4 ASSIGN 00H–07H
N/A, MULTI-VIEW, INPUT-VIEW, STILL-VIEW, PROGRAM, SUB PROGRAM, PREVIEW,
AUX
02H 01H 26H LED DIMMER 01H–08H 1–8
02H 01H 27H LCD DIMMER 01H–08H 1–8
02H 01H 28H LCD MENU 00H–01H LEFT, RIGHT
02H 01H 29H TALLY FRAME - MULTI-VIEW 00H–01H OFF, ON
02H 01H 2AH TALLY FRAME - STILL-VIEW 00H–01H OFF, ON
02H 01H 2BH
AUX/SOURCE INDICATOR - MULTI-
VIEW
00H–01H OFF, ON
02H 01H 2CH
AUX/SOURCE INDICATOR - STILL-
VIEW
00H–01H OFF, ON
02H 01H 2DH
EXTERNAL REC INDICATOR - MULTI-
VIEW
00H–01H OFF, ON
02H 01H 2EH AUDIO LEVEL METER - MULTI-VIEW 00H–01H OFF, ON
02H 01H 2FH PREVIEW LABEL - MULTI-VIEW 00H–01H OFF, ON
02H 01H 30H PREVIEW LABEL - STILL-VIEW 00H–01H OFF, ON
02H 01H 31H PREVIEW LABEL SIZE 00H–01H SMALL, NORMAL
02H 01H 32H MULTI-VIEW LAYOUT - LEFT 00H–04H PROGRAM, SUB PROGRAM, PREVIEW, AUX, BLACK
02H 01H 33H MULTI-VIEW LAYOUT - RIGHT 00H–04H PROGRAM, SUB PROGRAM, PREVIEW, AUX, BLACK
02H 01H 34H AUTO INPUT DETECT 00H–01H OFF, ON
02H 01H 35H AUTO FAN CONTROL 00H–01H OFF, ON
02H 01H 36H TEST PATTERN 00H–0CH
OFF, COLOR BARS 75%, COLOR BARS 100%, RAMP, STEP, HATCH, DIAMOND,
CIRCLE, COLOR BARS 75%-SP, COLOR BARS 100%-SP, RAMP-SP, STEP-SP,
HATCH-SP
02H 01H 37H TEST PATTERN MOTION 00H–02H DISABLE, SLOW, FAST
02H 01H 38H TEST TONE LEVEL 00H–03H O, -20dB, -10dB, 0dB
02H 01H 39H TEST TONE FREQUENCY L 00H–02H 500Hz, 1kHz, 2kHz
02H 01H 3AH TEST TONE FREQUENCY R 00H–03H 500Hz, 1kHz, 2kHz
02H 01H 3BH AUTO OFF (240min.) 00H–01H OFF, ON
02H 01H 3CH VIDEO SWITCHER BUTTON MODE 00H–03H INPUT SELECT, AUX, SCENE MEMORY, MACRO
02H 01H 3DH USB OUTPUT FORMAT 00H–01H YUY2 & MJPEG, YUY2
02H 01H 3EH DASHBOARD LCD ASSIGN A 00H–05H
N/A, CLOCK, STREAM/RECORD STATUS 1, STREAM/RECORD STATUS 2, USER
BUTTON 1/2, USER BUTTON 3/4
02H 01H 3FH DASHBOARD LCD ASSIGN B 00H–05H
N/A, CLOCK, STREAM/RECORD STATUS 1, STREAM/RECORD STATUS 2, USER
BUTTON 1/2, USER BUTTON 3/4
02H 01H 40H DASHBOARD HDMI ASSIGN A 00H–05H
N/A, CLOCK, STREAM/RECORD STATUS 1, STREAM/RECORD STATUS 2, USER
BUTTON 1/2, USER BUTTON 3/4
02H 01H 41H DASHBOARD HDMI ASSIGN B 00H–05H
N/A, CLOCK, STREAM/RECORD STATUS 1, STREAM/RECORD STATUS 2, USER
BUTTON 1/2, USER BUTTON 3/4
