Roland VR-6HD

17
MIDI Implementation
À AUDIO LEVEL METER
Address Parameter Name Sys.Ex.Value Meaning of Value
02H 02H 00H
LEVEL METER POSITION - AUDIO IN 1 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 01H LEVEL METER POSITION - AUDIO IN 2 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 02H LEVEL METER POSITION - AUDIO IN 3 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 03H LEVEL METER POSITION - AUDIO IN 4 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 04H LEVEL METER POSITION - AUDIO IN 5 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 05H LEVEL METER POSITION - AUDIO IN 6 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 06H LEVEL METER POSITION - AUDIO IN 7/8 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 07H LEVEL METER POSITION - USB IN 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 08H LEVEL METER POSITION - Bluetooth IN 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 09H LEVEL METER POSITION - AUDIO PLAYER 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 0AH LEVEL METER POSITION - VIDEO IN 1 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 0BH LEVEL METER POSITION - VIDEO IN 2 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 0CH LEVEL METER POSITION - VIDEO IN 3 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 0DH LEVEL METER POSITION - VIDEO IN 4 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 0EH LEVEL METER POSITION - VIDEO IN 5 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 0FH LEVEL METER POSITION - VIDEO IN 6 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 10H LEVEL METER POSITION - VIDEO PLAYER 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 11H LEVEL METER POSITION - MAIN BUS 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 12H LEVEL METER POSITION - AUX 1 BUS 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 13H LEVEL METER POSITION - AUX 2 BUS 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 14H LEVEL METER POSITION - USB OUT 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 15H LEVEL METER POSITION - STREAM/RECORD 00H–01H PRE FADER (PFL), POST FADER (AFL)
02H 02H 16H AUDIO LEVEL CUSTOM 1 ASSIGN 00H–15H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER, MAIN BUS, AUX 1 BUS, AUX 2 BUS, USB OUT, STREAM/RECORD
02H 02H 17H AUDIO LEVEL CUSTOM 2 ASSIGN 00H–15H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER, MAIN BUS, AUX 1 BUS, AUX 2 BUS, USB OUT, STREAM/RECORD
02H 02H 18H AUDIO LEVEL CUSTOM 3 ASSIGN 00H–15H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER, MAIN BUS, AUX 1 BUS, AUX 2 BUS, USB OUT, STREAM/RECORD
02H 02H 19H AUDIO LEVEL CUSTOM 4 ASSIGN 00H–15H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER, MAIN BUS, AUX 1 BUS, AUX 2 BUS, USB OUT, STREAM/RECORD
02H 02H 1AH AUDIO LEVEL CUSTOM 5 ASSIGN 00H–15H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER, MAIN BUS, AUX 1 BUS, AUX 2 BUS, USB OUT, STREAM/RECORD
02H 02H 1BH AUDIO LEVEL CUSTOM 6 ASSIGN 00H–15H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER, MAIN BUS, AUX 1 BUS, AUX 2 BUS, USB OUT, STREAM/RECORD
02H 02H 1CH AUDIO LEVEL CUSTOM 7 ASSIGN 00H–15H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER, MAIN BUS, AUX 1 BUS, AUX 2 BUS, USB OUT, STREAM/RECORD
02H 02H 1DH AUDIO LEVEL CUSTOM 8 ASSIGN 00H–15H
AUDIO IN 1–6, AUDIO IN 7/8, USB IN, Bluetooth IN, AUDIO PLAYER, VIDEO IN 1–6,
VIDEO PLAYER, MAIN BUS, AUX 1 BUS, AUX 2 BUS, USB OUT, STREAM/RECORD
À PANEL LOCK
Address Parameter Name Sys.Ex.Value Meaning of Value
02H 03H 00H
TOUCH SCREEN 00H–01H OFF, ON
02H 03H 01H VIDEO SWITCHER BUTTON 1 00H–01H OFF, ON
02H 03H 02H VIDEO SWITCHER BUTTON 2 00H–01H OFF, ON
02H 03H 03H VIDEO SWITCHER BUTTON 3 00H–01H OFF, ON
02H 03H 04H VIDEO SWITCHER BUTTON 4 00H–01H OFF, ON
02H 03H 05H VIDEO SWITCHER BUTTON 5 00H–01H OFF, ON
02H 03H 06H VIDEO SWITCHER BUTTON 6 00H–01H OFF, ON
02H 03H 07H CUT BUTTON 00H–01H OFF, ON
02H 03H 08H AUTO BUTTON 00H–01H OFF, ON
02H 03H 09H MODE - INPUT SELECT BUTTON 00H–01H OFF, ON
02H 03H 0AH MODE - AUX BUTTON 00H–01H OFF, ON
02H 03H 0BH MODE - SCENE MEMORY BUTTON 00H–01H OFF, ON
02H 03H 0CH MODE - MACRO BUTTON 00H–01H OFF, ON
02H 03H 0DH TRANSITION - MIX BUTTON 00H–01H OFF, ON
02H 03H 0EH TRANSITION - WIPE BUTTON 00H–01H OFF, ON
02H 03H 0FH TRANSITION - SPLIT BUTTON 00H–01H OFF, ON
02H 03H 10H PinP&KEY 1 - POSITION H 00H–01H OFF, ON
02H 03H 11H PinP&KEY 1 - POSITION V 00H–01H OFF, ON
02H 03H 12H PinP&KEY 1 - PVW BUTTON 00H–01H OFF, ON
02H 03H 13H PinP&KEY 1 - PGM BUTTON 00H–01H OFF, ON
