Roland VR-6HD

18
MIDI Implementation
Address Parameter Name Sys.Ex.Value Meaning of Value
02H 03H 14H
PinP&KEY 2 - POSITION H 00H–01H OFF, ON
02H 03H 15H PinP&KEY 2 - POSITION V 00H–01H OFF, ON
02H 03H 16H PinP&KEY 2 - PVW BUTTON 00H–01H OFF, ON
02H 03H 17H PinP&KEY 2 - PGM BUTTON 00H–01H OFF, ON
02H 03H 18H DSK - PVW BUTTON 00H–01H OFF, ON
02H 03H 19H DSK - PGM BUTTON 00H–01H OFF, ON
02H 03H 1AH MONITOR BUTTON 00H–01H OFF, ON
02H 03H 1BH PANEL SETUP BUTTON 00H–01H OFF, ON
02H 03H 1CH OUTPUT FADE BUTTON 00H–01H OFF, ON
02H 03H 1DH AUDIO MIXER 1 - SETUP BUTTON 00H–01H OFF, ON
02H 03H 1EH AUDIO MIXER 1 - SOLO BUTTON 00H–01H OFF, ON
02H 03H 1FH AUDIO MIXER 1 - MUTE BUTTON 00H–01H OFF, ON
02H 03H 20H AUDIO MIXER 1 - LEVEL FADER 00H–01H OFF, ON
02H 03H 21H AUDIO MIXER 2 - SETUP BUTTON 00H–01H OFF, ON
02H 03H 22H AUDIO MIXER 2 - SOLO BUTTON 00H–01H OFF, ON
02H 03H 23H AUDIO MIXER 2 - MUTE BUTTON 00H–01H OFF, ON
02H 03H 24H AUDIO MIXER 2 - LEVEL FADER 00H–01H OFF, ON
02H 03H 25H AUDIO MIXER 3 - SETUP BUTTON 00H–01H OFF, ON
02H 03H 26H AUDIO MIXER 3 - SOLO BUTTON 00H–01H OFF, ON
02H 03H 27H AUDIO MIXER 3 - MUTE BUTTON 00H–01H OFF, ON
02H 03H 28H AUDIO MIXER 3 - LEVEL FADER 00H–01H OFF, ON
02H 03H 29H AUDIO MIXER 4 - SETUP BUTTON 00H–01H OFF, ON
02H 03H 2AH AUDIO MIXER 4 - SOLO BUTTON 00H–01H OFF, ON
02H 03H 2BH AUDIO MIXER 4 - MUTE BUTTON 00H–01H OFF, ON
02H 03H 2CH AUDIO MIXER 4 - LEVEL FADER 00H–01H OFF, ON
02H 03H 2DH AUDIO MIXER 5 - SETUP BUTTON 00H–01H OFF, ON
02H 03H 2EH AUDIO MIXER 5 - SOLO BUTTON 00H–01H OFF, ON
02H 03H 2FH AUDIO MIXER 5 - MUTE BUTTON 00H–01H OFF, ON
02H 03H 30H AUDIO MIXER 5 - LEVEL FADER 00H–01H OFF, ON
02H 03H 31H AUDIO MIXER 6 - SETUP BUTTON 00H–01H OFF, ON
02H 03H 32H AUDIO MIXER 6 - SOLO BUTTON 00H–01H OFF, ON
02H 03H 33H AUDIO MIXER 6 - MUTE BUTTON 00H–01H OFF, ON
02H 03H 34H AUDIO MIXER 6 - LEVEL FADER 00H–01H OFF, ON
02H 03H 35H AUDIO MIXER 7 - SETUP BUTTON 00H–01H OFF, ON
02H 03H 36H AUDIO MIXER 7 - SOLO BUTTON 00H–01H OFF, ON
02H 03H 37H AUDIO MIXER 7 - MUTE BUTTON 00H–01H OFF, ON
02H 03H 38H AUDIO MIXER 7 - LEVEL FADER 00H–01H OFF, ON
02H 03H 39H MAIN - SETUP BUTTON 00H–01H OFF, ON
02H 03H 3AH MAIN - MUTE BUTTON 00H–01H OFF, ON
02H 03H 3BH MAIN - LEVEL FADER 00H–01H OFF, ON
02H 03H 3CH AUX 1 KNOB 00H–01H OFF, ON
02H 03H 3DH AUX 2 KNOB 00H–01H OFF, ON
02H 03H 3EH USB OUT KNOB 00H–01H OFF, ON
02H 03H 3FH STREAM/RECORD KNOB 00H–01H OFF, ON
02H 03H 40H AUDIO EFFECT - SETUP BUTTON 00H–01H OFF, ON
02H 03H 41H AUDIO EFFECT - AUDIO EFFECT 1 BUTTON 00H–01H OFF, ON
02H 03H 42H AUDIO EFFECT - AUDIO EFFECT 2 BUTTON 00H–01H OFF, ON
02H 03H 43H AUDIO EFFECT - AUDIO EFFECT 3 BUTTON 00H–01H OFF, ON
02H 03H 44H AUDIO PLAYER - SETUP BUTTON 00H–01H OFF, ON
02H 03H 45H AUDIO PLAYER - AUDIO PLAYER 1 PAD 00H–01H OFF, ON
02H 03H 46H AUDIO PLAYER - AUDIO PLAYER 2 PAD 00H–01H OFF, ON
02H 03H 47H AUDIO PLAYER - AUDIO PLAYER 3 PAD 00H–01H OFF, ON
02H 03H 48H AUDIO PLAYER - AUDIO PLAYER 4 PAD 00H–01H OFF, ON
02H 03H 49H AUDIO PLAYER - AUDIO PLAYER 5 PAD 00H–01H OFF, ON
02H 03H 4AH AUDIO PLAYER - AUDIO PLAYER 6 PAD 00H–01H OFF, ON
02H 03H 4BH AUDIO PLAYER - LEVEL KNOB 00H–01H OFF, ON
À SCENE MEMORY
Address Parameter Name Sys.Ex.Value Meaning of Value
02H 04H 00H
START UP 7FH–00H–1FH LAST MEMORY, MEMORY 1–32
02H 04H 01H START UP - PRIORITY 00H–01H MEMORY, PANEL
02H 04H 02H MEMORY PROTECT 00H–01H OFF, ON
02H 04H 03H FADE TIME 00H–28H 0.0–4.0sec
