Roland VR-6HD

25
MIDI Implementation
À RS-232/TALLY/GPO/GPI/KEYPAD
Address Parameter Name Sys.Ex.Value Meaning of Value
02H 12H 00H
RS-232 00H–01H OFF, ON
02H 12H 01H RS-232 - BAUDRATE 00H–02H 9600, 38400, 115200
02H 12H 02H TALLY/GPO - TEMPLATE 00H–02H TALLY, GPO, TALLY/GPO
02H 12H 03H TALLY/GPO - TALLY/GPO 1 00H–49H
PGM VIDEO IN 1–6, PGM STILL 1–16, PGM VIDEO PLAYER, PGM INPUT 1–6, PST
VIDEO IN 1–6, PST STILL 1–16, PST VIDEO PLAYER, PST INPUT 1–6, GPO 1–16
: : : :
02H 12H 12H TALLY/GPO - TALLY/GPO 16 00H–49H
PGM VIDEO IN 1–6, PGM STILL 1–16, PGM VIDEO PLAYER, PGM INPUT 1–6, PST
VIDEO IN 1–6, PST STILL 1–16, PST VIDEO PLAYER, PST INPUT 1–6, GPO 1–16
02H 12H 13H
14H
GPI 1 00H 00H–04H 17H
See “Menu List” in the “Reference Manual” (PDF).
: : :
02H 12H 21H
22H
GPI 8 00H 00H–04H 17H
02H 12H 23H
24H
NUMERIC KYEPAD 0 00H 00H–04H 17H
: : :
02H 12H 35H
36H
NUMERIC KYEPAD 9 00H 00H–04H 17H
02H 12H 37H
38H
NUMERIC KYEPAD + 00H 00H–04H 17H
02H 12H 39H
3AH
NUMERIC KYEPAD - 00H 00H–04H 17H
02H 12H 3BH
3CH
NUMERIC KYEPAD * 00H 00H–04H 17H
02H 12H 3DH
3EH
NUMERIC KYEPAD / 00H 00H–04H 17H
02H 12H 3FH
40H
NUMERIC KYEPAD . 00H 00H–04H 17H
02H 12H 41H
42H
NUMERIC KYEPAD ENTER 00H 00H–04H 17H
02H 12H 43H TALLY SETTINGS - AUX 00H–01H DISABLE, ENABLE
02H 12H 44H TALLY SETTINGS - PinP&KEY 1 00H–01H DISABLE, ENABLE
02H 12H 45H TALLY SETTINGS - PinP&KEY 2 00H–01H DISABLE, ENABLE
02H 12H 46H TALLY SETTINGS - DSK 00H–01H DISABLE, ENABLE
À PREVIEW LABEL
* xxH: 20H–3AH (VIDEO IN 1–6, STILL 1–16, PROGRAM, SUB PROGRAM, PREVIEW, AUX)
Address Parameter Name Sys.Ex.Value Meaning of Value
02H xxH 00H
LABEL (0) 00H–7FH
02H xxH 01H LABEL (1) 00H–7FH
02H xxH 02H LABEL (2) 00H–7FH
02H xxH 03H LABEL (3) 00H–7FH
02H xxH 04H LABEL (4) 00H–7FH
02H xxH 05H LABEL (5) 00H–7FH
02H xxH 06H LABEL (6) 00H–7FH
02H xxH 07H LABEL (7) 00H–7FH
À CAMERA CONTROL COMMON
Address Parameter Name Sys.Ex.Value Meaning of Value
02H 50H 00H
CAMERA ID 00H–05H CAMERA 1–6
02H 50H 01H CAMERA CONTROL MODE 00H–01H OFF, ON
02H 50H 02H ALL CAMERAS LOAD 00H–01H OFF, ON
