Roland VR-6HD

26
MIDI Implementation
À CAMERA CONTROL
* xxH: 51H–56H (CAMERA 1–6)
Address Parameter Name Sys.Ex.Value Meaning of Value
02H xxH 00H
PROTOCOL 00H–06H N/A, JVC, Panasonic, Canon, VISCA over IP, PTZOptics, Avonic
02H xxH 01H
02H
IP ADDRESS 1 00H 00H–01H 7FH 0–255
02H xxH 03H
04H
IP ADDRESS 2 00H 00H–01H 7FH 0–255
02H xxH 05H
06H
IP ADDRESS 3 00H 00H–01H 7FH 0–255
02H xxH 07H
08H
IP ADDRESS 4 00H 00H–01H 7FH 0–255
02H xxH 09H LOGIN NAME 1 00H–7FH
02H xxH 0AH LOGIN NAME 2 00H–7FH
02H xxH 0BH LOGIN NAME 3 00H–7FH
02H xxH 0CH LOGIN NAME 4 00H–7FH
02H xxH 0DH LOGIN NAME 5 00H–7FH
02H xxH 0EH LOGIN NAME 6 00H–7FH
02H xxH 0FH LOGIN NAME 7 00H–7FH
02H xxH 10H LOGIN NAME 8 00H–7FH
02H xxH 11H PASSWORD 1 00H–7FH
02H xxH 12H PASSWORD 2 00H–7FH
02H xxH 13H PASSWORD 3 00H–7FH
02H xxH 14H PASSWORD 4 00H–7FH
02H xxH 15H PASSWORD 5 00H–7FH
02H xxH 16H PASSWORD 6 00H–7FH
02H xxH 17H PASSWORD 7 00H–7FH
02H xxH 18H PASSWORD 8 00H–7FH
02H xxH 19H PASSWORD 9 00H–7FH
02H xxH 1AH PASSWORD 10 00H–7FH
02H xxH 1BH PASSWORD 11 00H–7FH
02H xxH 1CH PASSWORD 12 00H–7FH
02H xxH 1DH PASSWORD 13 00H–7FH
02H xxH 1EH PASSWORD 14 00H–7FH
02H xxH 1FH PASSWORD 15 00H–7FH
02H xxH 20H PASSWORD 16 00H–7FH
02H xxH 21H CURRENT PRESET 7FH–00H–05H NONE, PRESET 1–6
02H xxH 22H PAN 7FH, 00H, 01H LEFT, STOP, LIGHT
02H xxH 23H TILT 7FH, 00H, 01H DOWN, STOP, UP
02H xxH 24H PAN/TILT SPEED 01H–18H 1–24
02H xxH 25H ZOOM 7EH–00H–02H WIDE (FAST), WIDE (SLOW), STOP, TELE (SLOW), TELE (FAST)
02H xxH 26H FOCUS 7FH, 00H, 01H NEAR, STOP, FAR
02H xxH 27H AUTO FOCUS 00H–01H OFF, ON
02H xxH 28H EXPOSURE 00H–01H MANUAL, AUTO
02H xxH 29H TALLY CHANNEL 00H–05H VIDEO IN 1–6
À AUDIO PLAYER COMMON
Address Parameter Name Sys.Ex.Value Meaning of Value
02H 60H 00H
AUDIO PLAYER BANK 00H–01H BANK A, BANK B
À AUDIO PLAYER
* xxH: 61H–6CH (AUDIO PLAYER A 1–6, AUDIO PLAYER B 1–6)
Address Parameter Name Sys.Ex.Value Meaning of Value
02H xxH 00H
AUDIO PLAYER NAME 1 00H–7FH
02H xxH 01H AUDIO PLAYER NAME 2 00H–7FH
02H xxH 02H AUDIO PLAYER NAME 3 00H–7FH
02H xxH 03H AUDIO PLAYER NAME 4 00H–7FH
02H xxH 04H AUDIO PLAYER NAME 5 00H–7FH
02H xxH 05H AUDIO PLAYER NAME 6 00H–7FH
02H xxH 06H AUDIO PLAYER NAME 7 00H–7FH
02H xxH 07H AUDIO PLAYER NAME 8 00H–7FH
