Roland VR-6HD

28
MIDI Implementation
ÁTally Area
À TALLY INFO
Address Parameter Name Sys.Ex.Value Meaning of Value
0CH 00H 00H
VIDEO IN 1 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 01H VIDEO IN 2 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 02H VIDEO IN 3 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 03H VIDEO IN 4 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 04H VIDEO IN 5 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 05H VIDEO IN 6 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 06H SILL 1 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 07H SILL 2 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 08H SILL 3 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 09H SILL 4 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 0AH SILL 5 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 0BH SILL 6 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 0CH SILL 7 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 0DH SILL 8 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 0EH SILL 9 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 0FH SILL 10 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 10H SILL 11 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 11H SILL 12 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 12H SILL 13 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 13H SILL 14 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 14H SILL 15 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 15H SILL 16 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 16H VIDEO PLAYER TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 17H INPUT 1 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 18H INPUT 2 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 19H INPUT 3 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 1AH INPUT 4 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 1BH INPUT 5 TALLY 00H–02H OFF, PGM, PST (read only)
0CH 00H 1CH INPUT 6 TALLY 00H–02H OFF, PGM, PST (read only)
ÁVideo Parameter (MEMORY 1) Area, Audio Parameter (MEMORY 1) Area–Video Parameter
(MEMORY32) Area, Audio Parameter (MEMORY32) Area
À MEMORY
* xxH xxH: The second and third bytes of the parameter address for the Video/Audio Area to read/write
Address Parameter Name Sys.Ex.Value Meaning of Value
10H 00H 00H
VIDEO PARAMETER (MEMORY 1) Load/rewrite video parameter stored in Memory 1
11H 00H 00H AUDIO PARAMETER (MEMORY 1) Load/rewrite audio parameter stored in Memory 1
12H 00H 00H VIDEO PARAMETER (MEMORY 2) Load/rewrite video parameter stored in Memory 2
13H 00H 00H AUDIO PARAMETER (MEMORY 2) Load/rewrite audio parameter stored in Memory 2
14H 00H 00H VIDEO PARAMETER (MEMORY 3) Load/rewrite video parameter stored in Memory 3
15H 00H 00H AUDIO PARAMETER (MEMORY 3) Load/rewrite audio parameter stored in Memory 3
16H 00H 00H VIDEO PARAMETER (MEMORY 4) Load/rewrite video parameter stored in Memory 4
17H 00H 00H AUDIO PARAMETER (MEMORY 4) Load/rewrite audio parameter stored in Memory 4
18H 00H 00H VIDEO PARAMETER (MEMORY 5) Load/rewrite video parameter stored in Memory 5
19H 00H 00H AUDIO PARAMETER (MEMORY 5) Load/rewrite audio parameter stored in Memory 5
1AH 00H 00H VIDEO PARAMETER (MEMORY 6) Load/rewrite video parameter stored in Memory 6
1BH 00H 00H AUDIO PARAMETER (MEMORY 6) Load/rewrite audio parameter stored in Memory 6
1CH 00H 00H VIDEO PARAMETER (MEMORY 7) Load/rewrite video parameter stored in Memory 7
1DH 00H 00H AUDIO PARAMETER (MEMORY 7) Load/rewrite audio parameter stored in Memory 7
1EH 00H 00H VIDEO PARAMETER (MEMORY 8) Load/rewrite video parameter stored in Memory 8
1FH 00H 00H AUDIO PARAMETER (MEMORY 8) Load/rewrite audio parameter stored in Memory 8
: :
: :
4EH 00H 00H VIDEO PARAMETER (MEMORY 32) Load/rewrite video parameter stored in Memory 32
4FH 00H 00H AUDIO PARAMETER (MEMORY 32) Load/rewrite audio parameter stored in Memory 32
