145
Is the network routing appropriate?
Try connecting the computer and the machine to the same hub, or connecting them directly using a crossover
cable. If this makes it possible to perform output, it means the problem is in the network itself.
Are the network settings correct?
If the cable connections are secure and no problem is found in the network itself, make sure that the IP ad-
dress and other such settings are appropriate. The settings on both the machine and the computer must be
appropriate. Redo the settings, checking to ensure that the IP address doesn’t conict with the IP address for
another device on the network, that the port setting for the software RIP species the IP address set on the
machine, that the settings have no typing errors, and for other such problems.
"Setup Guide" , p. 140 "Viewing Information about the System of This Machine"
Did the software RIP end abnormally?
Make sure the software RIP is running correctly, then switch the sub power switch o and back on.
"Roland VersaWorks Quick Start Guide"
The Media Heating System Doesn't Warm Up
Is media loaded?
The media heating system does not warm up to the preset temperature when is dark (by default).
Load media and wait for the machine to warm up.
P. 99, “Fully Utilize the Media Heating System”
Is the temperature of the room too low?
Use the machine in an environment where the temperature is 20 to 32°C (68 to 90°F).
Cannot cut off the media.
Is the separating knife mounted?
If the separating knife is not mounted, you cannot cut o the media.
P. 92, “Replacing the Separating Knife”
Are the cut rail mounted?
If the cut rail is not mounted, you cannot cut o the media.
P. 92, “Replacing the Separating Knife”
