Roland VS-540 User Manual

68
3
Maintenance
Checking for Remaining Ink and Replacing Cartridges
Checking for Remaining Ink
Procedure

Press .

Press several times until the screen shown on the left
appears.
Press
.
indicates the amount of ink remaining. When there are more
, the amount of ink remaining is larger.
* The display shows an approximate guide to the amount of remaining ink. It may differ somewhat
from the actual amount remaining.

Press to go back to the original screen.
MENU
INK REMAINING
1 2 3 4
5 6 7 8
W1200mm
SETUP SHEET
The number of cartridge slots
Amount of
ink remaining
Much
Little

Roland VS-540 Specifications

General

Maximum Print Width	54 inches
Connectivity	USB, Ethernet
Print Technology	Piezo inkjet
Resolution	1440 dpi
Media Thickness	Maximum 1.0 mm with liner
Media Roll Diameter	Maximum 210 mm
Media Roll Weight	Maximum 30 kg
Interface	USB 2.0, Ethernet
Power Requirements	AC 100 to 240 V ± 10%, 50/60 Hz
Ink Configuration	CMYK, Light Cyan, Light Magenta, White
