Roland XV-88 - Page 7

MAR, 2000 XV-88
7
CRYSTAL, RESONATOR / クリスタル、発振子
/ クリスタル、発振子 / クリスタル、発振子
/ クリスタル、発振子
00901912 MA-406 24.576MHZ TE24 CRYSTAL X2 on Main Board 1
01893790 MA-406 8.25MHZ CRYSTAL X1 on Main Board 1
01340745 MA-406 12MHZ CRYSTAL X3 on Main Board 1
ENCODER / エンコーダー
/ エンコーダー / エンコーダー
/ エンコーダー
01905467 EVE GC1 F20 24B ROTARY ENCODER EN1 on Panel-C Board 1
CONNECTOR / コネクター
/ コネクター / コネクター
/ コネクター
13429300 51048-1100(11P) CABLE HOLDER CN2 on Analog Board 1
# 02129623 SB20-10WS FOR PCB CONNECTOR CN1 on Analog Board 1
# 02014445 CONNECTOR 20FE-BT-VK-N CN11 on Main Board 1
02019012 26FE-BT-VK-N CONNECTOR CN14 on Main Board 1
01908645 16FE-BT-VK-N CONNECTOR CN13 on Main Board 1
01908634 14FE-BT-VK-N CONNECTOR CN12 on Main Board 1
02018990 34FE-BT-VK-N CONNECTOR CN1 on EXP Base Boaerd,CN5 on Main Board 1 +1
# 02019001
32FE-BT-VK-N FOR WIRING CONNECTOR CN2 on EXP Base Boaerd,CN9,CN6 on Main Board 1 +2
# 02129723
SB20-15WS FOR PCB 2MM PITCH CONNECTOR CN1 on Main Board 1
13369598 52147-0310 3PIN WIRE TRAP CN5 on AFT Board ,CN15 on Main Board 1 +1
13369606 52147-1110(11P) WIRE TRAP CN18 on Main Board 1
13369926 53253-0410 (2MM PITCH) CONNECTOR CN10 on Main Board 1
13369592 B7B-XH-A(7P) JST CONNECTOR CN19 on Main Board 1
# 02018689 32FE-ST-VK-N FOR PCB CONNECTOR CN1 on Panel-A Board 1
# 02018723 26FE-ST-VK-N FOR PCB CONNECTOR CN6 on Panel-C Board 1
# 02018712
20FE-ST-VK-N FOR WIRING CONNECTOR CN3 on Panel-B Board 1
13439311 520314-2 CONNECTOR CN4 on AFT Board 1
13429833 52411-0402 40P CONNECTOR CN5,CN6 on EXP Base Boaerd 2
02010078 TX25-80P-6ST-E1 CONNECTOR CN3,CN4 on EXP Base Boaerd 2
WIRING, CABLE / ワイヤリング、ケーブル
/ ワイヤリング、ケーブル / ワイヤリング、ケーブル
/ ワイヤリング、ケーブル
# 02019112 WIRING W1 1+1+1+1
# 02019090 WIRING 4X600-P2.0-51065-51065-F 1
# 02019101 WIRING 7X1200-P2.5-XHP-XHP-F 1
# 02019089 WIRING 15X400-P2.0-SB20-51065-F 1
01014867 RIBON CABLE 3X650-P2.0 1
# 02231689 BAN CARD BNCD-P=1.25-K-34-320 1
# 02231678 BAN CARD BNCD-P=1.25-K-32-400 1
# 02231712 BAN CARD BNCD-P=1.25-K-26-550 1
# 02231701 BAN CARD BNCD-P=1.25-K-20-450 1
# 02231690 BAN CARD BNCD-P=1.25-K-32-160 1
SCREW / ねじ類
/ ねじ類 / ねじ類
/ ねじ類
40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 2+10+2+2+2
40010278 SCREW M3X12 BINDING MACHINE BZC 6
40010134 SCREW M4X20 TRUSS MACHINE BZC 13
40010734 SCREW M3X12
BINDING HEAD TAPPING A1 FE ZC 3
40012145 SCREW M4X14
TRUSS TAPPING A1 FE BZC 12
40128512 SCREW 4X25X20
PAN WASHER HEAD TAPTITE B BZC 13
# 40346289 SCREW 4X12 OVAL HEAD TAPTITE B NI 10
40011067 SCREW 3X8 BINDING TAPTITE B FE ZC 24+24
40011123 SCREW M4X8 BINDING TAPTITE B BZC 2 +2
40239734 SCREW 3X6 PAN VWH TAPTITE B ZC 7
40013067 SCREW M3X8
PAN MACHINE W/SW+SMALL PW ZC 4
40237101 SCREW M3X8
PAN MACHINE W/SW+PW FE BZC 5
# 40344256 SCREW 3X6
PAN HAEAD TAPTITES FE BZC 4
40010745 SCREW M3X16
BINDING HEAD TAPPING A1 FEZC 4
40011734 NUT M4X11.5
ANCHOR B FOR WOOD BZC 2
40019434 NUT M5X12
ANCHOR B FOR WOOD BZC 2
PACKING / 梱包材
/ 梱包材 / 梱包材
/ 梱包材
# 02129578 LOWER PAD CNTR 1
# 02018923 UPPER PAD L 1
# 02018945 UPPER PAD R 1
# 02018956 LOWER PAD 2
# 02018989 UPPER PAD CNTR 1
# 02018912 PACKING CASE 1
MISCELLANEOUS / その他
/ その他 / その他
/ その他
12569249 LITHIUM BATTERY CR2032 220MAH/3V 1
40128534 DOUBLE FACED
ADHESHIVE TAPE
#575X W30MM 30M (CM) 10
40122612 NITTO ACETATE TAPE #5 BLACK W10MM 30M 20P
15+120
# 02230590 CLIP CLAMP B-4S 2
# 02235323 LEAF B 3
# 02235345 LEAF A 6
# 02231756 INSULATING SHEET INSULATING 1
40017356 COATING CLIP CS-4 1
40016512 INSULOK TIE 80M/M T-18S 1
12189815 BATTERY HOLDER BH-32 BT1 on Main Board 1
# 40122889 DOUBLE-FACED TAPE #501 W10MM 20M 20P(CM) 2
22265286 KEY FELT 226-286 1
00569156 CUSHION T1X25X1200 1
12359105 RUBBER FOOT W RS-09 235-105 4
# 40231845 STRAIGHT PIN 6X20 FOR WOOD 3
ACCESSORIES (STANDARD) / 標準付属品
/ 標準付属品 / 標準付属品
/ 標準付属品
# 02019167 AC CORD ASSY 120V UP-880-J01 1
13499219 AC CORD SET (100V) DC-382-J01 VFF2P 1
13499221 AC CORD SET (230V) EC-511-E07 H03VVH2-F 2P 1 +1
13499222 AC CORD SET (240VA) SC-078-J02 ES206-75HMA 1
# 71565912 OWNER'S MANUAL JAPANESE 1
# 71565945 OWNER'S MANUAL ENGLISH 1
40232334
保証書
JAPAN ONLY 1
