Rollplay Mini Cooper S - Assemble Left Rear Wheel

11
Assemble the Left Rear Wheel
Rim
Snap
Pin
Left washer
Rear wheel
Assemble the Left Rear Wheel
1. Turn the car body upside down, pull the rear axle out of the hole, use
scissors to cut off the xing cable tie on the gear box (as shown in
gure a).
2. Rotate the gear box upwards, insert the rear axle through the hole in the
middle of the gear box and the car body (as shown in gure b).
3. Place rear wheel (the side with the gear teeth facing inward) and the
washer into the rear axle in order, ensure that the rear wheel gear teeth t
the gear box, lock it with the snap pin, then snap the rim onto the wheel
to complete the assembly (as shown in gure c).
a
b
c
