17
Battery Removal
2. Disconnect the red battery connector (A) from the red engine
connector (B).
1. Unlock and remove the seat.
3. Loosen screw and remove the battery strap.
4. Remove the battery from the vehicle.
Note: It is not necessary to remove the battery for charging. However,
if the battery does not reach the outlet, then it can be removed for
charging.
Battery strap
Battery
Screw
A
B
To Next Page
