Room essentials 430238 - Step 6: Attach Skirts and Brackets

11
Push six HIDDEN CAMS (1F) into the SKIRTS (F and G). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM.
Fasten two METAL BRACKETS (4G) to the SKIRT (G) exactly as shown. Use two BLACK 9/16" LARGE HEAD SCREWS (1S).
NOTE: Be sure the BRACKETS are even with the edge of the SKIRT.
430238
step 6.
Arrow
1F
2F
Metal end
Arrow
1F
2F
Metal end
Do not tighten the HIDDEN CAMS in this step.
(1F) x 6
hidden cam
(2F) x 6
cam dowel
(4G) x 2
metal bracket
(1S) x 2
black 9/16" large head screw
4G
G
F
F
