Room essentials 430238 - Drawer Assembly: Braces and Backs

17
Push one HIDDEN CAM (1F) into a DRAWER BRACE (M67). Then, insert the metal end of a CAM DOWEL (2F) into the HIDDEN CAM.
Fasten the DRAWER BRACE (M67) to the UPPER DRAWER FRONT (H). Tighten one HIDDEN CAM.
Fasten a DRAWER BACK (D182) to the DRAWER SIDES (D44 and D45) and DRAWER BRACE (M67). Use fi ve BLACK 1-9/16" FLAT HEAD SCREWS (30S).
NOTE: You should start each SCREW a few turns before completely tightening any of them.
Repeat Steps 11-12 for the lower drawers. The angled edge of the lower drawer front will be opposite from the upper drawer front.
430238
step 12.
(30S) x 20
black 1-9/16" fl at head screw
Arrow
1F
2F
Metal end
(1F) x 4
hidden cam
(2F) x 4
cam dowel
Surface with
HIDDEN CAM
M67
H
D44
D45
M67
M67
H
D182
Hidden part using
recycled material.
Color may vary.
Be sure the DRAWER
BOTTOM inserts into the
DRAWER BACK groove.
