18
Fasten a DRAWER RIGHT (35AC) to the RIGHT DRAWER SIDE (D44) and a DRAWER LEFT (35AD) to the LEFT DRAWER SIDE (D45). Use four GOLD 5/16"
FLAT HEAD SCREWS (3S) through holes #1 and #2.
NOTE: The glides are not intended to rotate.
Repeat this step for the other drawers.
430238
step 13.
VIEW THE DRAWER GLIDE VIDEO
(35AC) x 4
drawer right
(35AD) x 4
drawer left
(3S) x 16
gold 5/16" fl at head screw
1
2
1
2
Glide end
Glide end
D44
D45
Drawer Slide
Center the screw in the oval hole.
To Next Page
