Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw
diagrams (SHOWN ACTUAL SIZE). Pay close attention to the color of each screw. You may receive extra hardware with your unit.
430238
(35AA) x 8
universal cabinet rail
(35AC) x 4
drawer right
(35AD) x 4
drawer left
(1F) x 18
hidden cam
(2F) x 18
cam dowel
(15F) x 16
wood dowel
(97) x 1
furniture tipping restraint kit
(8G) x 4
drawer front bracket
(4G) x 2
metal bracket
(1N) x 21
nail
(1S) x 28
black 9/16" large head screw
(3S) x 32
gold 5/16" fl at head screw
(30S) x 20
black 1-9/16" fl at head screw
(113S) x 4
black 1-15/16" fl at head screw
