2. Characteristics
1) GSM 850/900/1800/1900 Quad band
2) Wide for voltage input range: 7-100VDC
3) GPS continuous positioning, GPRS timing interval
4) Get location via SMS & web platform & APP.
5) Built-in G-sensor, theft-proof
6) Setting three phone numbers for alarm alert
7) Power off alarm when the power supply is disconnected intentionally (with backup battery)
8) Support geo-fence alarm, over speed alarm
2.1. Specifications
Items
Parameters
work voltage
7VDC-100VDC
work current
30mA-55mA
GSM module
inside contain frequency GSM 850/900/1800/1900Mhz
Communication protocol
TCP
GPS module
GPS SiRF-Star III
GPS sensitivity
-157dBm
C/A coding
1.023 MHz chip rate
Channels
22 channels examine track
Position accuracy
5m
Cold boot
35s
Work temperature
-20～70℃
Humidity
5% to 95% noncondensing
Terminal size
60mm × 32mm ×13mm
Gravity Acceleration
<4g
Operating Temperature
-20℃—65℃
Humidity
5%—95%
weight
50g
2.2 Device wiring diagram
There are only two cables for standard version: red cables to positive of car battery, black cable
to negative.
