11. Wiring Diagram
RD-023MS 9
11.Wiring Diagram
Caution
Make sure that there are no mis-wiring and short-circuiting and do not turn power
on before wiring correctly. There is danger of fire or failure.
Please tighten the terminals with the torque of less than 3.5kgf・cm (0.35N・m).
Please use the wire rod with the cross-section area corresponding to current value.
※In microstep mode, a sine curve current which made effective value the run current value set by
run current adjustment trimmer flows. The maximum current value which runs on the lead wire
of motor is run current × 2 .
ex.) Run current: 3A → Max. current value is 4.2A. ( 4.2(A)2(A)3 =× )
Use twisted wire pair for the signal input wiring. Please tighten the terminals less than 3.5kgf・cm
(0.35N・m). (Proper torque is 2.5kgf・cm (0.25N・m))
Fig.14. Wiring Diagram
11-1 Suitable Motor
You can use any HB(hybrid) or PM(permanent magnet) stepping motor with rating of 0.3 to 3A/ph.
Select motors with rating of less than supply voltage × 0.7(V).
RORZE 2-Ph Stepping Motors (Torque -- 1kgf・cm = 13.9oz・in Inertia -- 1g・c㎡ = 5.46745×10
-3
oz・in
2
)
Holding
Torque
Model No.
(kgf・cm) (N・m)
FullStep
Angle
(Degree)
Rated
Current
(A/phase)
Rotor
Inertia
(g・c㎡)
Resistance
(Ω)
Inductance
(mH)
RM2414S/D 1.4 0.14 1.8 1.5 30 1.3 0.96
RM2424S/D 2.4 0.24 1.8 1.5 53 1.75 2.2
RM2621S/D 2.1 0.21 1.8 3.0 57 0.36 0.48
RM2640S/D 4.0 0.39 1.8 3.0 100 0.6 0.8
RM2690S/D 8.0 0.78 1.8 3.0 210 0.77 1.58
RM26A3S/D 13.0 1.3 1.8 3.0 360 0.9 2.2
Color of RORZE motor’s wire
Terminal
CA CB A A B B
RORZE MOTOR Black White Red Yellow Blue Orange
!
A C A A
B
CB
B
GND
18-40VDC
8 LEAD WIRE MOTOR 6 LEAD WIRE MOTOR
5V
Controller
5V
5V
+
-
+
-
+
-
+
-
GND
CA
CB
A
A
B
B
ST OPRU N
CURRENT
010010
ALARM
2P IN
CW
CCW
CLK
UD
2CK
1CK
80320
1
64 50 400
0000 0
0
10
0
0
0
0
1
1
1
0
0
0
1
0
1
0
0
0
0
0
11
DIVISION
1
0
- D1
- D2
- D3
- D4
- D5
3A
0-1
2CK1C K
1.5A
RD-023MS
2P MIC RO STEP DRIV ER
DC18V -40V
MADE IN
JAPAN
