Rosewill N600PCE User Manual

Wireless N Dual Band Adapter N600PCE User Manual
5
1.4 Product Specification
Chipset
Ralink RT5592
Standard
IEEE 802.11a/b/g/n
Bus Type
PCI Express interface
Frequency Band
2.4000~2.4835GHz
5.150~5.825GHz
Data Rate
11a: 6/9/12/24/36/48/54Mbps
11b: 1/2/5.5/11Mbps
11g: 6/9/12/24/36/48/54Mbps
11n (20MHz): MCS0-15 (up to 144Mbps)
11n (40MHz): MCS0-15 (up to 300Mbps)
Output Power
2.4GHz: 11b: 17+/-1.5dBm, 11g: 14+/-1.5dBm, 11n: 13+/-1.5dBm
5GHz: 11a:13±1.5 dBm, 11n(20/40MHz): 13±1.5 dBm
Security
64/128 bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES);
WPS button
Antenna
External 3dBi Dipole Antenna with RP-SMA Connector x 2
OS support
Windows XP/Vista/7 32 and 64 bit;
Dimension
0.86 x 4.76 x 3.46 inches (22 x 121 x 88 mm (w/o Antenna))
Temperature
Operating: 32~104°F (0~40°C); Storage: -40~158°F (-40~70°C)
Humidity
Operating: 10~90% (Non-Condensing); Storage: Max. 95%
(Non-Condensing)
1.5 System Requirement
You must have at least the following
 A desktop PC with an available PCI-Express slot
 At least a 300MHz processor and 32MB of memory
 Windows OS for WinXP, Vista, and 7
 A CD-ROM Drive
 A 802.11n、802.11g or 802.11a/b Wireless (and Dual Band) Access Point/Router (for
infrastructure Mode) or another 802.11n、802.11g or 802.11b wireless (and Dual Band)
adapter (for Ad-Hoc; Peer-to-Peer networking mode).
1.6 LED Status
This PCIE Adapter contains one LED. Please refer to the following description for LED definition.
LED Name
Light Status
Description
Link
On
Link to a wireless access point
Off
Not linked to any wireless access point
