44 • DashBoard Menus SRG-2200 User Guide (v6.0)
Composite Timecode
AES Audio 1 and 2
Table 6.11 Composite Timecode Items
Item Parameter Notes
Running Time # This is a DashBoard representation of the time
code being inserted into the composite output
Timecode Standard This read only field shows the current video format
Offset Second # Allows the user to add an offset (in seconds) to the
timecode embedded in the composite output
Offset frame # Allows the user to add an offset (in frames) to the
timecode embedded in the composite output
Date in User Bits Off Allows the user to turn off, turn on Date, or turn on
Date including time zone. This will be in
embedded int he timecode user bits
Date as BCD
Date as BCD (including
timezone)
Daylight Saving Time Processing
Is Daylight Savings
(DST Active?
Read-only field to show current status of DST
Table 6.12 AES Audio 1 and 2 Items
Item Parameter Notes
Channel - #
Tone Type 400Hz
800Hz
1KHz
Sweep Sweep ramps the frequency from 20Hz to 20KHz
in 3 seconds
Step Step includes spot tones of: 400Hz, 4KHz, 9KHz,
14KHz, 800Hz, 5KHz, 10KHz, 15KHz, 1KHz,
6KHz, 11KHz, 16KHz, 2KHz, 7KHz, 12KHz,
3KHz, 8KHz, 13KHz
A-Maj Chord Uses the first 8 channels and includes the
frequencies (from the Equi- Tempered Scale):
329.628Hz = E, 440.000Hz = A, 554.276Hz = C#,
659.256Hz = E, 880.000Hz = A, 1108.552Hz =
C#, 1318.512Hz = E, and 1760.000Hz = A
A-Maj Scale Similar to Step but uses only the notes from the
C-Major chord (from the Harmonic Scale):
1056Hz = C, 1187Hz = D, 1319Hz = E, 1407Hz =
F, 1584Hz = G, 1760Hz = A, 1979Hz = B, and
2112Hz = C
Spot Frequency
Sample 1
