SRG-2200 User Guide (v6.0) Specifications • 65
Physical Specifications
Clearance
Mechanical Characteristics
Environment Characteristics
Table 9.8 Clearance Requirements
Category Performance Requirement Reference Information
Clearance Side 50mm (2.00”)
Rear 75mm (3.00”)
Table 9.9 Mechanical Specifications
Category Performance Requirement Reference Information
Dimensions Height 43.5mm (1.71”)
Width 482.5mm (19.00”)
Depth 405mm (15.95”)
Table 9.10 Environment Characteristics
Category Performance Requirement Reference Information
Temperature Operating 0°C to +40°C
Non-operating -20°C to +60°C
Relative Humidity Operating 20% to 80% relative humidity (%RH)
at up to +40°C, non-condensing
Non-operating 5% to 90% relative humidity (%RH) at
up to +60°C, non-condensing
Altitude Operating To 2,000m (6,561ft)
Non-operating To 12,192m (40,000ft)
Vibration Operating 2.65m/s2 (0.27Grms), 5Hz to 500Hz,
10 minutes per axis, three axes
Non-operating 22.3m/s2 (2.28Grms), 5Hz to 500Hz,
10 minutes per axes, three axes
Shock Non-operating 294m/s2 (30G), half-sine, 11ms
duration
