SRG-2200 User Guide (v6.0) DashBoard Menus • 45
Slots 8, 9, 10: Color Black and Tri-Level Sync Tabs
Select Slots 8,9,10: Color Black Set, Select and configure the format wand other parameters of the analog
reference outputs to suit your requirements. The following Tabs are available to allow comprehensive configuration
of format, modifiers, Timecode, and signal Timing Offsets.
Tone Type Forced to Blitz
Forced to Lip-sync
Forced to Sample 1
Spot Frequency # Allows the user to select any frequency between
20Hz and 20KHz (in 1Hz steps).
Gain (dB) # The options in the field are: Silence, -60dB to
+18dB (in 1dB steps). The upper limit is actually
set by the dBFS menu (detailed below).
Interrupt Off Glits can only be selected on odd (left) channels.
Glits also uses the associated even (right) channel
in the pair to create a stereo audio identification
sequence.
Blits can only be selected on channel 01. Blits also
uses the next five channels to create a 5.1 Surround
Sound Audio Identification sequence.
1 second
3 seconds
Glits
Blits
dBFS Silence
-24 to -18dB
Audio Type PCM Audio
PCM Silence
Dolby-E
Forced to PCM Silence
Forced to Sample 1
Not Embedded
Table 6.12 AES Audio 1 and 2 Items
Item Parameter Notes
