SRG-2200 User Guide (v6.0) Specifications • 63
AES/EBU Audio Unbalanced Outputs Specifications
Timing Offset Range Full frame
Resolution
270Mbps
<1/54.00MHz
Resolution
1.5Gbps
<1/74.25MHz
Resolution 3Gbps <1/148.50HMz
Embedded Audio 270Mbps Number of channels: 4 per SDI 20bit audio
1.5Gbps Number of channels: 16 per SDI 24bit audio
3Gbps Number of channels: 16 per SDI 24bit audio
Frequency 1Hz-20KHz 1Hz resolution
Amplitude Silence and -78dBFS to 0dBFS 1dB resolution
Pre-emphasis None
Interruption Programmable 1 second, 3 second, EBU
TECH 3304, Glits, Blits
a. 270Mbps SDI (SMPTE 259M), 1.5Gbps SDI (SMPTE 292M), 3Gbps (SMPTE 424M)
Table 9.4 AES/EBU Audio Unbalanced Outputs
Category Performance Requirement Reference Information
Output Connector Type 3 x BNC
Number of Outputs 2 x unbalanced Audio on BNC AES-3
AES-3id
1 x unbalanced DARS on BNC DARS is indicated as
“non-PCM audio” and
“Locked” and “Grade 1
reference signal”
Output Impedance and
Required Termination
75ohm
Signal Amplitude 1V ±10%
Rise and Fall Time 5ns > Rise/Fall < 44ns 10% to 90%
Jitter 8ns Typically 2ns
Audio Parameters Frequency 1Hz-20kHz Steps of <1Hz
Amplitude Silence and -78dBFS to
0dBFS
1dB resolution
Pre-emphasis None
Interruption Programmable 1 second, 3 second, EBU
TECH 3304, Glits, Blits
Quantized Resolution 24bits
Table 9.3 Serial Digital Interface
Category Performance Requirement Reference Information
