Contents
Technical Specifications 4
Key Features 5
Mounting the AC-C31 Controller 6
Wiring Diagrams 8
Normal, Secure, & Master Users 10
Modes Of Operation 11
Changing the Modes of Operation 12
Request To Exit (REX) Button 14
Case and Back Tamper 14
BL-D40 External Sounder 15
Entering Programming Mode 17
Exiting Programming Mode 17
1 Changing the Open Code 1 18
2 Changing the Open Code 2 18
3 Changing the Programming Code 19
4 Changing the Normal / Secure Code 20
5 Changing the Normal / Bypass Code 20
Door Chime Settings 20
6 Setting Fail Safe / Secure Operation 22
Setting Tamper Siren Time 22
Setting the Lock Strike Release Time 22
7 Enrolling Primary and Secondary Codes 23
8 Deleting Primary and Secondary Codes 26
0 Return to Factory Default Settings 28
Replacing a lost Programming Code 29
Replacing a lost Normal / Secure Code 29
Glossary 30
INTRODUCTION
INSTALLATION
FEATURES AND CONCEPTS
PROGRAMMING THE AC-C31
APPENDIX
TECHNICAL SUPPORT
3
6
16
33
AC-C31
Introduction
Equipment provided
The following is provided as part of every AC-C31 package:
The AC-C31 is a keypad access control unit.
The unit accepts up to 500 users and provides entry via the use of
PIN codes.
- AC-C31 Access Control Unit.
- Installation Kit
- Installation and Operating Instructions
Fail Safe (Power to Lock) or Fail Secure (Power to Open)
12 to 16V DC (From a Regulated Power Supply)
Normally Open Type - Switch is closed when pressed.
Provides Siren, Bell, and Chime functions to AC-C31
Other Rosslare accessories can be found at Rosslare's
Web Site:
http://www.rosslare.com.hk
Additional Equipment Required
1) Electric Lock Strike Mechanism
2) Power Supply with Backup Battery
3) Request To Exit (REX) Button
4) BL-D40 External Sounder (Optional)
