Technical Specifications
10 AC-x32 Series Installation and Programming Manual
2. Technical Specifications
Electrical Characteristics
Operating Voltage Range
12–16 VDC
From a regulated power supply
Input Current (excluding
attached devices)
Standby: 40 mA
Max: 90 mA
Relay Outputs
• Lock Strike Relay – Electronic, 3.5 A
with built-in suppressor protection
• Auxiliary Relay – Form C, 1 A
Inputs
• REX – N.O., Dry Contact
• Auxiliary Input (In/Monitor)
• Monitor Mode – N.C., Dry Contact
• Input Mode – N.O., Dry Contact
LEDs
Two tri-colored LEDs
Built-In Proximity Reader
• Read Range: 90 mm (3.5 in.)*
• Modulation: ASK at 125 kHz
• Compatible cards: All 26-Bit EM cards
* Measured using a Rosslare proximity card or equivalent. Range also
depends on electrical environment and proximity to metal.
