Page 40
07/04
Replacing a lost Programming Code
1) Remove power from the AC-S43
2) Press the REX button
3) Apply power to the unit with REX button pressed
4) Release the REX button
5) You now have 15 seconds to program a new Programming Code
into the unit using the initial default code 1234, before the
controller reverts to the existing code.
Replacing a lost Normal / Secure Code
1) Remove power from the AC-S43
2) Press the REX Button
3) Apply power to the unit with REX button pressed.
4) Release the REX Button
5) You now have 15 seconds to program a new Normal / Secure
code 3838 in order to return to Normal Mode, where you may
enter programming mode to program a new Normal / Secure
code.
Note: The AC-S43 must be in Normal Mode otherwise this will
not work. Make sure that the Mode LED is green before
proceeding.
Note: The AC-S43 must be in Secure Mode otherwise this will
not work. Make sure that the Mode LED is red before
proceeding.
AC-S43
Glossary
valid users. In this mode the door
A
may be released by anyone pressing
Access Control: Primarily refers to
the star button.
a device or set of devices controlling
C
the entry of people traveling through
a door or set of doors. Cards: See Proximity Cards
Ajar Delay: The time allowed for a Case Tamper: The electronic
door to be left open before sounding tamper signal advising the controller
an alert and / or activating the that the case has been opened.
Auxiliary Relay. Code Assignment: The process of
Amplitude Shift Keying (ASK): The assigning which Output(s) (Lock
typ e of dat a com mun ica tio ns Strike Relay and / or Auxiliary Relay)
between the Proximity Card and the are to be activated when a valid code
Proximity Reader. is entered.
ASK: An abbreviation of "Amplitude
D
Shift Keying".
Direct Shunt: The arrangement in
Auxiliary Input: The term used for
which an external input (such as a
the programmable input electrical
door monitor) is connected directly to
signal from an external device such
the Auxiliary Relay allowing the
a Door Monitor switch or Auxiliary
Auxiliary Output to be activated after
REX button.
the direct shunt delay elapses. This
Auxiliary Code: The four digit code
leaves the Auxiliary Input available
used to activate the Auxiliary Output
for Normal / Secure mode toggle.
for testing purposes during
Default Factory Setting: The
installation.
settings that the controller is
Auxiliary Output: The term used for
preprogrammed with when the
the Relay Output in the AC-S43 that
controller is manufactured.
may be programmed to activate upon
Direct Shunt Delay: The delay time
different system events such as
(user programmed) used in Direct
Tamper, Forced Door Event, Door
Shunt (See Direct Shunt).
Ajar, etc.
Door Bell: The alert sound activated
B
when the door star button on the AC-
Back Tamper: The ele ctr oni c S43 is pressed. (Requires the BL-
tamper signal advising the controller D40 External Sounder)
that the controller has been removed Door Chime: The alert sound
from the wall. activated when the lock strike
Bypass Code: The four digit code unlocks the door after a valid code
used to ch ange the M ode o f has been presented. (Requires the
Operation of the AC-S43 from BL-D40 External Sounder)
Normal to Bypass Mode or vice
versa.
Bypass Mode: A Mode of Operation
where door access is not restricted to
Page 41
07/04
AC-S43
