Page 4
07/04
Introduction
Equipment provided
The following is provided as part of every AC-S43 package:
The AC-S43 is a waterproof keypad access control unit with backlit
keypad suitable for external or internal applications.
The unit accepts up to 500 users and provides entry via the use of
PIN codes.
- AC-S43 Access Control Unit.
- Installation Kit
- Installation and Operating Instructions
Additional Equipment Required
1) Electric Lock Strike Mechanism
Fail Safe (Power to Lock) or Fail Secure (Power to Open)
2) Power Supply with Backup Battery
12 to 24V DC (From a Regulated Power Supply)
or
16 to 24V AC (From a Transformer)
3) Request To Exit (REX) Button
Normally Open Type - Switch is closed when pressed.
4) BL-D40 External Sounder (Optional)
Provides Siren, Bell, and Chime functions to AC-S43
Other Rosslare accessories can be found at Rosslare's
Web Site:
http://www.rosslaresecurity.com
AC-S43
07/04
Technical Specification
Electrical Characteristics
Operating Voltage Range:
12 to 24V DC From a Regulated Power Supply
or
16 to 24V AC From a Transformer
Maximum Input Current:
Standby: 35mA Not including attached devices
Max: 90mA Not including attached devices
Relay Outputs:
Lock Strike Relay Form C, 5A
Auxiliary Relay Form C, 5A
Inputs:
REX N.O., Dry Contact
Auxiliary Input (In / Monitor) N.O., Dry Contact
LEDs
Two Tri-colored LEDs
Environmental Characteristics
Operating Temperature: -40 F to 150 F (-40 C to 65 C)
Operating Humidity: 0 to 95% (Non-Condensing)
Suitable for outdoor use. (IP 65)
Mechanical Characteristics
Dimensions:
5.91" (150mm) L x 1.65" (42mm) W x 1.00" (27mm) D
Weight:
0.90 lbs (400g)
Page 5
AC-S43
