Rosslare AC-S43 User Manual

Wiring Diagrams
Page 10
07/04
AC-S43
(-)
ELECTRIC LOCK
STRIKE
COM
N.C.
N.O.
REX / BL
LOCK
V IN
REX / BL
(-)
(-)
(+)
(+)
FAIL SAFE
or
FAIL SECURE
REX
COMMON
POWER SUPPLY
12V - 24V DC
or
16V - 24V AC
FROM TRANSFORMER
{
GROUND
BLACK
RED
GREEN
GRAY
BROWN
PURPLE
AC-S43
Transorb: 1.5KE47C - Connect to load terminals
(Optional transorb, Not Supplied)
07/04
Page 11
AC-S43
Wiring the Auxiliary Input and Output
IN / MONITOR
V IN
COMMON
POWER SUPPLY
(-)
(+)
12V - 24V DC
or
16V - 24V AC
FROM TRANSFORMER
Auxiliary
Load
AUXILIARY
INPUT
(MONITOR)
(-)
AUX. IN
IN / MONITOR
COM
N.C.
N.O.
AUX.
{
GROUND
BLACK
RED
WHITE
YELLOW
ORANGE
BLUE
AC-S43
Transorb: 1.5KE47C - Connect to load terminals
(Optional transorb for inductive loads, Not Supplied)

Rosslare AC-S43 Specifications

General

Brand	Rosslare
Model	AC-S43
Category	IP Access Controllers
Language	English
