Wiring the BL-D40 External Sounder
AC-S43
REX / BL
REX / BL
(+)
(-)
BL-D40
COMMON
POWER SUPPLY
(-)
(+)
12V - 24V DC
or
16V - 24V AC
FROM TRANSFORMER
V IN
GROUND
BLACK
RED
GREEN
AC-S43
