Installation
AY-x55 Family Installation and Programming Manual 11
5. Secure the front cover by using the supplied security screw in the
installation kit. An L-shaped tool is provided for use when
tightening the security screw.
3.2 Wiring Instructions
The reader is supplied with a 41-cm (16”) pigtail, having a 6-
conductor cable.
To connect the unit to the controller:
1. Prepare the unit's cable by cutting the cable jacket back 2.5 cm
(1”) and strip the wire 2.5 cm (1”).
2. Prepare the controller cable by cutting the cable jacket back 2.5
cm (1”) and strip the wire 2.5 cm (1”).
3. Splice the unit’s pigtail wires to the corresponding controller
wires and cover each connection.
Refer to Table 1 and to the wiring diagrams provided on the
following pages.
Table 1: Wiring Colors
Color Output
Red +VDC
Black Ground
White Data 1/Clock
Green Data 0 / Data
Brown LED Control
Purple Tamper
4. If the tamper output is used, connect the purple wire to the
correct input on the controller.
5. Trim and cover all unused conductors.
