Functionality
12 AY-x55 Family Installation and Programming Manual
4. Functionality
This chapter explains how the functionality of the reader.
4.1 Transmit Mode
When the AY-x55 is in Transmit mode, it is ready to receive data from
a presented proximity card or from an entered PIN code.
When the reader is in Transmit mode,
the Transmit LED is red and the
Program LED is off.
When a PIN entry is being
transmitted, the Transmit LED flashes
green.
Keyboard data can be sent via one of eight different keypad
transmission formats (see Section 4.2.3).
4.2 Programming the AY-x55
Programming the AY-x55 is done solely via the unit's keypad driven
Programming Menu System. During the AY-x55’s manufacturing
process, certain codes and settings are pre-programmed. These
settings are called the default factory settings.
Table 2 shows the names of all the AY-x55 reader menus.
Default factory settings are marked by a "*" sign.
