Technical Specifications
AY-x55 Family Installation and Programming Manual 9
2. Technical Specifications
Electrical Characteristics
AY-S55 AY-T55 AY-T55B
Power Supply
Linear type (recommended)
Voltage Range
5 to 16 VDC
Input Current
Standby: 30 mA
Max: 120 mA
Standby: 30 mA
Max: 120 mA
Standby: 90 mA
Max: 180 mA
Tamper Output
Open collector, active low, max. sink current 32 mA
LED Control Input
Dry contact, N.O.
Environmental Characteristics
Operating Temp.
Range
-31°C to 63°C (-25°F to 145°F)
Operating
Environment
Suitable for outdoor use (meets IP65)
Operating
Humidity Range
0 to 95% (non-condensing)
Dimensions
Height x Width x
Depth
150 x 42 x 27
mm (5.91 x 1.65
x 1.06 in.)
120 x 65 x 27 mm
(4.72 x 2.56 x
1.06 in.)
120 x 65 x 27 mm
(4.72 x 2.56 x
1.06 in.)
Weight
400 g (14.11 oz) 500 g (17.64 oz) 502 g (17.71 oz)
