Controller Operation
32 AYC-Qx4 Family Installation and Programming Manual
5. Controller Operation
Upon power-on reset, the unit searches for the presence of a secured
intelligent power supply. If a secured intelligent power supply is
detected, then the unit is automatically configured as a secure access
control unit, as indicated by two short beeps.
The Lock Strike and Auxiliary outputs, as well as the REX input, are
not located on the unit, eliminating the possibility of unauthorized
entry to the restricted area.
The use of a proximity card is for the AYC-Q64 model only.
5.1 Normal, Secure, and Master Users
The units accept up to 500 users and provide entry via the use of PIN
codes and/or Proximity cards. Each user is provided with two code
memory slots, Memory Slot 1 (Primary code) and Memory Slot 2
(Secondary code).
The PIN code length has several options. The PIN code length can be a
set number of 4, 5 or 6 digits or it can be a 4–8 digits option. When
choosing the 4–8-digit option, please note that you should either
enter zeros before the code, or press # at the end (for example, if
your code is 12345, enter either 00012345 or 12345#).
Entering a code refers to either PIN or card depending on the
model you have.
The way in which the two memory slots are programmed determines
a user’s access level and also determines the way in which the unit
grants access in its three modes of operation. There are three user
levels:
Normal
A Normal user only has a Primary code and is only granted access
when the unit is in Normal or Bypass mode.
