Controller Operation
AYC-Qx4 Family Installation and Programming Manual 45
Aux.
Mode
Aux. Input
Function
Aux.
Output
Activated
by
Aux.
Relay
Aux. Settings
(in seconds)
3 Normal/Secure
switch
Tamper
event
N.C. 01 to 99 Aux.
relay release time
4 Normal/Secure
switch
Direct shunt N.O. 01 to 99 Shunt
time
5 Door Monitor Shunt N.C. 01 to 99
Maximum shunt
time
6 Door Monitor Forced door N.C. 01 to 99 Forced
delay
7 Door Monitor Door ajar N.C. 01 to 99 Ajar
delay
8 LED control – Green
Valid code N.O. 01 to 99 Aux.
relay release time
9 LED control Red Valid code N.O. 01 to 99 Aux.
relay release time
The following subsections describe each Auxiliary mode.
5.9.9.1 Auxiliary Mode 0
Auxiliary input function: Activates the auxiliary output
Auxiliary output activated by: Valid user code, Auxiliary code, and
Auxiliary input
For example, in Auxiliary Mode 0, the controller can function as a
2-door controller. The auxiliary relay is to be attached to the lock on
the second door. The auxiliary setting defines the door open time for
the second door. The auxiliary input is to be attached to the REX
pushbutton for the second door. The Door Monitor input feature for
the second door is not enabled when using this mode.
