USER'S AND
MAINTENANCE
MANUAL
01/31/2020
Air Compressor : D185T4F-DB
Copyright © 2014, ROTAIR S.P.A. - All rights reserved. This manual is intellectual property of ROTAIR S.P.A.
Its full or partial reproduction is forbidden under any form, on any support and by any means, without the
written authorization by ROTAIR S.P.A.
The user must periodically check the condition of the lifting equipment and
machine-supplied lifting hook and replace it if it is no longer appropriate or safe.
No other hooking and lifting systems are allowed except those that are provided
with the machine.
This pictogram shows the hooking system to lift the machine.
WARNING
OVERHANGING
LOADS
6.2
Safety recommendations concerning lifting
A purposely-allocated opening protected by a rubber cover is
located in the upper panel of the hood and allows for easy access
to the lifting hook.
List of the operations for the safe lifting of the machine:
1) Make sure that the lifting device (crane, hoist, etc.) is of the
appropriate payload for the weight of the unit and that it is
maintained appropriately.
2) In the case that the lifting device is installed on the truck, use the
side anti-tilting stabilizers.
3) Attach the hook of the lifting device to the hooking point of
the compressor (Figure 6.2-1).
4) Lift the unit slowly and without sudden movements to
prevent the load from swaying excessively.
5) Before transporting, always check that there are no parts
that may fall off during transport.
6) Check the status of tie-downs or chains before starting the transport
operations.
7) In any case, always make sure that the machine is solidly secured to the loading deck of the transport
vehicle and balanced appropriately.
8) Communicate appropriately when the compressor is lifted to or from the transport vehicle.
9) Never leave the lifting area with the compressor hanging.
10) Do not stand or walk under the hanging load.
Figure 6.2-1
