Rotary SPOA10NB Series User Manual

16
BEARING BAR WITH 5 HOLES
BEARING BAR
WITH 3 HOLES
DO NOT use holes marked with arrows.
BEARING BAR WITH 5 HOLES
Fig. 23c
Fig. 24a
Use holes marked “A” for Right Front
and Left Rear.
A
A
Use holes marked “A” for Left Front
and Right Rear.
A
A
BEARING BAR WITH 3 HOLES
Use holes marked with arrow for Right Front
and Left Rear.
BEARING BAR WITH 5 HOLES
Use holes marked with arrow for Left Front
and Right Rear.
Fig. 24b
